Preci-Dip 4 Way Right Angle Through Hole 2 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder Termination 831-87-004-20-001101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 100, 150V ac |
| Brand | Preci-Dip |
| Orientation | Right Angle |
| Current | 3A |
| Length | 8mm |
| Depth | 2.2mm |
| Width | 2.8mm |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Liquid Crystal Polymer |
| Contact Material | Beryllium Copper Alloy, Brass |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2mm |
| Contact Plating | Gold, Tin |
| Number of Contacts | 4 |
Key Features
- The socket features 4 contacts with a 2 mm pitch.
- Contacts are made of beryllium copper alloy and brass for durability.
- Contact plating includes gold and tin ensuring reliable conductivity.
- Designed with a right angle orientation and through hole mounting type.
- Housing is constructed from fibreglass reinforced liquid crystal polymer for high temperature resistance.
- Operates between -55°C minimum and 125°C maximum temperature.
- Termination is through soldering ensuring secure connections.
- Compact dimensions with length 8 mm, width 2.8 mm, and depth 2.2 mm.
Product Description
Preci-Dip model 831-87-004-20-001101 is a 4 Way Right Angle Through Hole SIL Socket with a 2 mm pitch designed for electronic component interconnections supporting up to 3A current. This socket type is suited for industrial, electronics manufacturing, and laboratory applications where reliable electrical connections are required.
The contacts are made from beryllium copper alloy and brass, plated with gold and tin to ensure excellent conductivity and corrosion resistance. With a solder termination type, it provides robust mechanical and electrical joining suitable for PCB assemblies.
The socket housing is made from fibreglass reinforced liquid crystal polymer, offering high resistance to heat and providing durability in demanding environmental conditions. This connector can operate over a wide temperature range from -55°C to 125°C and supports voltages of 100 V AC and 150 V DC.
Its right angle orientation and through hole mounting are optimized for space-saving PCB layouts. The physical dimensions of 8 mm length, 2.8 mm width, and 2.2 mm depth make it compact and fit for precise electronic designs.
Manufactured in Switzerland, this product aligns with strict quality standards ensuring reliability and long service life. The socket features 4 contacts with a 2 mm pitch. Contacts are made from beryllium copper alloy and brass.
Gold and tin plating provides excellent connectivity. Right angle orientation for efficient PCB layout. Through hole solder termination for strong connection. Fibreglass reinforced polymer housing for durability. Current rating of 3A with voltages up to 150 V DC.
Operating temperature range from -55°C to 125°C. Compact size: Length 8 mm, Width 2.8 mm, Depth 2.2 mm. Manufactured in Switzerland under high quality standards.
This Preci-Dip SIL Socket is ideal for electronic assemblies in industrial, manufacturing, and laboratory environments. It offers reliable electrical and mechanical performance for precision PCB mounting applications. Browse our range of industrial electronic components at EnvMart to find compatible sockets and connectors for your projects.
Explore more products in our SIL Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 3A, making it suitable for various electronic applications.
It supports voltages of up to 150 V DC and 100 V AC, ensuring compatibility with a range of electronic systems.
The operating temperature range is from -55°C to 125°C, allowing it to function in extreme conditions.
The contacts are made from beryllium copper alloy and brass, providing good conductivity and durability.
This socket features a pitch size of 2 mm, which is standard for many PCB applications.
It contains 4 contacts, facilitating multiple connections in a compact form factor.
The termination type is solder, ensuring secure and reliable connections for PCB assemblies.
It is designed with a right angle orientation, optimizing space on the PCB for efficient layouts.
The housing is constructed from fibreglass reinforced liquid crystal polymer, providing high temperature resistance.
The dimensions are 8 mm in length, 2.8 mm in width, and 2.2 mm in depth, making it compact for electronic designs.
This SIL socket is manufactured in Switzerland, adhering to strict quality standards.
It is suited for industrial, electronics manufacturing, and laboratory applications requiring reliable electrical connections.
