Preci-Dip 2 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 100 V ac, 150 V dc, 3A Current 801-87-002-20-002101

Preci-Dip 801-87-002-20-002101 is a 2 Way SIL Socket featuring a right angle orientation and through hole mounting style, designed with a 2.54 mm pitch to suit standard electronic applications. Operating at 100 V ac and 150 V dc voltage ratings, this socket type ensures reliable performance for electronic circuits requiring up to 3A current capacity. The contact material is a high-quality beryllium copper alloy combined with brass, plated with durable tin and gold to provide excellent conductivity and resistance to wear and corrosion.

The housing is manufactured from fibreglass reinforced polycyclohexylenedimethylene terephthalate, offering robust mechanical strength and stability under diverse industrial environments. With operating temperature ranging from -55°C to 125°C, it is suitable for use in demanding laboratory, manufacturing, and electronic assembly settings. The solder termination type promotes secure and reliable circuit connections, while the compact dimensions (5.08 mm length, 2.95 mm width, and 2.54 mm depth) optimize PCB space layout.

This SIL socket does not carry specific certifications but complies with UL 94V-0 standards for flame retardancy, enhancing safety in electronic device construction. Originating from Switzerland, it exemplifies precision engineered quality and consistent performance.

Constructed with beryllium copper alloy and brass contact material. Capable of handling 3 ampere current, suitable for various electronic circuits. Contact plating includes tin and gold for enhanced conductivity and corrosion resistance.

Equipped with fibreglass reinforced polycyclohexylenedimethylene terephthalate housing for durability. Operates reliably between -55°C and 125°C, accommodating harsh conditions. Designed for solder termination type and through hole mounting for secure installation.

Compact dimensions: length 5.08 mm, width 2.95 mm, depth 2.54 mm facilitating efficient PCB space utilization.

This product is suitable for industrial electronic applications including electronic component assembly, PCB manufacturing, laboratory equipment, and instrumentation. It ensures stable electrical connections and enhanced durability in manufacturing, laboratory, and industrial contexts.
