SMC Pneumatic Guided Cylinder 16mm Bore, MXS Series, 100 mm Stroke, Double Acting, Aluminium Alloy Body MXS16-100

SMC MXS16-100 Pneumatic Guided Cylinder is a high-precision pneumatic actuator featuring a 16mm bore and 100mm stroke length. Designed within the MXS Series, this guided cylinder provides smooth, accurate, and reliable double acting motion, ideal for industrial applications requiring consistent positioning and compact force generation.

Constructed with an aluminium alloy body, it is engineered for durability and lightweight performance. The integrated slide bearing guide ensures stable piston rod movement and enhances the cylinder's service life by reducing wear.

This unit supports a maximum operating pressure of 0.7 Mpa and rubber cushioning for smooth operation at both ends, minimizing impact noise and mechanical shock. It operates efficiently within a temperature range of -10°C to 60°C and supports piston speeds reaching up to 500mm/s, making it suitable for diverse manufacturing, automation, and fluid power tasks.

The design includes a through hole mounting configuration and an M5 piston rod thread size, facilitating easy installation and compatibility with standard industrial equipment. Its compact overall dimensions of 210mm length, 62mm width, and 40mm height allow it to fit into constrained spaces without sacrificing strength.

Manufactured in Japan, the MXS16-100 model is supplied in new condition and is suited for applications in industrial automation, robotics, pneumatic machinery, and process control systems. This precision air slide table series embodiment offers users excellent control and reliability. The compact, guided design minimizes vibration and enhances accuracy during linear motion tasks.

This cylinder is ideal for industrial pneumatic guided motion requiring repeatable and precise actuation. Lightweight aluminium body combined with durable slide bearing guide enhances operational longevity. Double acting pneumatic cylinder with rubber cushioning for controlled stop and impact reduction.

Fits applications up to 0.7 Mpa operating pressure with wide temperature tolerance. Compact dimensions and standard mounting facilitate easy integration into equipment. Widely used across manufacturing, industrial automation, and fluid power control systems.

Designed and manufactured to high quality standards in Japan ensuring reliability. Explore more Pneumatic Guided Cylinders and accessories in the hydraulic and pneumatic tools category at EnvMart for your industrial automation needs.
