SMC Pneumatic Guided Cylinder 16mm Bore 40mm Stroke Double Acting Aluminium Alloy Body MXS16-40

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Guided Cylinder 16mm Bore 40mm Stroke Double Acting Aluminium Alloy Body MXS16-40



Category Pneumatic Guided Cylinder Brand SMC Condition New

Specifications

Country of Origin	Japan
Brand	SMC
Body Material	Aluminium Alloy
Maximum Operating Pressure	0.7 Mpa
Height	40mm
Length	97mm
Model	MXS16-40
Gross Weight	640g
Width	62mm
Mount Type	Through Hole
Series	MXS
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-10°C
Stroke Length	40mm
Bore Diameter	16mm
Action Type	Double Acting
Cushioning Type	Rubber
Guide Type	Slide Bearing
Piston Rod Thread Size	M5

Key Features

The cylinder features a through hole mount type for secure installation.
It supports a maximum operating pressure of 0.7 Mpa with rubber cushioning for smooth operation.
Designed with a slide bearing guide type for stable piston movement.
Operates efficiently within -10°C to 60°C temperature range.
Equipped with an M5 piston rod thread size suitable for various applications.
Compact dimensions of 97mm length, 62mm width, and 40mm height enable versatile use.
Lightweight design weighing 640 grams to facilitate easy integration.
Manufactured in Japan ensuring high quality and reliability.

Product Description

The SMC MXS16-40 pneumatic guided cylinder is engineered to provide precise and reliable performance in industrial applications requiring guided pneumatic motion. This double acting cylinder features a 16mm bore and a 40mm stroke length housed in a durable aluminium alloy body optimized for compact force generation.

Designed with a through hole mount type, the cylinder allows for secure and adaptable installation in various mechanical assemblies. It supports a maximum operating pressure of 0.7 Mpa, complemented by rubber cushioning that ensures smooth deceleration of the piston to reduce wear and noise.

The integrated slide bearing guide type guarantees stable piston rod movement, enhancing the accuracy of positioning across repetitive cycles. Its piston rod has an M5 thread size enabling straightforward mechanical connections.

Operating temperature ranges from -10°C to 60°C, allowing this guided cylinder to perform reliably in diverse industrial environments including manufacturing automation, packaging machines, and material handling systems.

The device’s compact dimensions of 97mm length, 62mm width, and 40mm height, combined with a weight of just 640 grams, facilitate versatile mounting in space-constrained setups.

Manufactured in Japan, the MXS series embodies SMC's commitment to quality and precision pneumatic solutions. This model is part of the MXS range offering bore sizes from 10mm to 32mm with variable stroke lengths addressing multiple application needs.

Through hole mounting ensures secure installation. Rubber cushioning improves operational smoothness. Slide bearing guide enhances stability and precision. Compact size for flexible integration. Wide operating temperature range.

Lightweight aluminium alloy body. Suitable for industrial automation and fluid power systems.

Select SMC Pneumatic Guided Cylinders for dependable linear motion control in industrial, manufacturing, and fluid power applications. Explore more pneumatic components in EnvMart’s Hydraulics & Pneumatics category.
