SMC 160 mm Pneumatic Piston Rod Cylinder Double Acting Both Ends Tapped Air Cushion Aluminium Alloy CD85

SMC CD85N16-160C-B Pneumatic Piston Rod Cylinder is a high-quality industrial pneumatic actuator with a 160 mm stroke length. This double acting cylinder features an aluminium alloy body providing excellent corrosion resistance while maintaining lightweight construction. It is designed for precision fluid power applications in industrial automation, manufacturing, and mechanical systems.

The cylinder supports a double acting action type, allowing controlled piston movement in both directions. The mounting is via both ends tapped style, offering installation flexibility. An air cushion type cushioning system enhances operational smoothness and durability by absorbing impact forces during piston deceleration.

With a single rod type and female piston rod featuring metric thread standards, this model supports compatibility and ease of use in various pneumatic circuits. The cylinder operates effectively up to a maximum temperature of 60°C and achieves piston speeds up to 1500 mm/s, suitable for high-speed pneumatic applications.

Constructed in compliance with ISO 6432 standards, the CD85 series guarantees mounting repeatability accuracy and includes abrasion-resistant seals, providing outstanding service life even in dusty environments. The barrel and piston rod consist of stainless steel elements and double-swaged anodised aluminium end caps for an airtight seal and corrosion resistance.

For assembly convenience, the cylinder is supplied with a piston rod locknut and nose-mounting nut, complemented by large spanner flats and a space-saving design. These features collectively enable convenient installation and secure mechanical connections in industrial, manufacturing, HVAC, and fluid power systems.

Double acting piston rod cylinder for precise pneumatic control. Aluminium alloy body provides corrosion resistance and durability. Mount type with both ends tapped for flexible installation. Air cushioning improves operational smoothness.

Complies with ISO 6432 standards for quality assurance. Maximum piston speed of 1500 mm/s supports high-speed operations. Operating temperature range up to 60°C for diverse environments. Includes piston rod locknut and nose-mounting nut for easy assembly.

Manufactured in Vietnam with long service life components. Explore the extensive range of pneumatic cylinders at EnvMart for high-performance pneumatic solutions suitable for industrial automation, laboratory equipment, and manufacturing.
