SMC 125 mm Pneumatic Piston Rod Cylinder Double Acting Both Ends Tapped Air Cushion Aluminium Alloy CD85

Free Delivery in India | Lowest Global Shipping Charges

SMC 125 mm Pneumatic Piston Rod Cylinder Double Acting Both Ends Tapped Air Cushion Aluminium Alloy CD85



Category Pneumatic Piston Rod Cylinder Brand SMC Condition New

Specifications

Country of Origin	India
Brand	SMC
Body Material	Aluminium Alloy
Length	234mm
Model	CD85
Mount Type	Both Ends Tapped
Series	CD85
Maximum Operating Temperature	60°C
Stroke Length	125mm
Rod Type	Single
Action Type	Double Acting
Standards/Approvals	ISO 6432
Cushioning Type	Air Cushion
Piston Rod Gender	Female
Piston Rod Thread Standard	Metric

Key Features

Constructed from aluminium alloy body for corrosion resistance.
Both ends tapped mount type for versatile installation options.
Equipped with air cushioning for smooth operation and reduced impact.
Single rod type with female piston rod gender and metric thread standard.
Maximum operating temperature of 60 degrees Celsius suitable for varied industrial environments.
Conforms to ISO 6432 standards ensuring quality and reliability.
Designed for maximum piston speed of up to 1500 mm/s.
Includes abrasion-resistant seals and replaceable piston rod seals for enhanced durability.

Product Description

SMC CD85 pneumatic piston rod cylinder features a robust aluminium alloy body with a 125 mm stroke length and double acting action type suitable for precise pneumatic applications. This cylinder is built to meet ISO 6432 standards and offers excellent corrosion resistance with stainless steel barrel and piston rod combined with anodised aluminium end caps.

The double-swaged end caps provide an airtight seal and enhanced durability, while air cushioning reduces impact for smooth and reliable operation. This cylinder is engineered for a maximum piston speed of 1500 mm/s and a maximum operating temperature of 60°C, making it suitable for demanding industrial, manufacturing, and HVAC pneumatic systems.

Designed with a single rod featuring a female piston rod gender and metric thread standard, the CD85 cylinder also provides easy installation with both ends tapped mounting options and large spanner flats to facilitate mounting and maintenance.

The SMC C85 series cylinders incorporate abrasion-resistant seals and replaceable piston rod seals to ensure long service life even in dusty environments. Their low friction design allows for efficient pneumatic actuation across various industrial use cases including automation, material handling, and fluid power control.

Constructed from high-grade aluminium alloy and stainless steel components for corrosion resistance. Complies with ISO 6432 for dimensional and performance accuracy. Double acting with air cushioning to minimize wear and provide smooth movement.

Compact length of 234 mm supports space-saving installation. Designed for industrial, manufacturing, and HVAC pneumatic applications.

Experience reliable and durable pneumatic control with the SMC CD85 Pneumatic Piston Rod Cylinder, engineered to enhance operational efficiency in laboratory, industrial, and commercial environments. Browse more pneumatic cylinders and actuators at EnvMart for your automation needs.
