STMicroelectronics Silicon Junction Rectifier Diode Single 1.5 A 200 V DO-15 Through Hole STTH1R02QRL

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics Silicon Junction Rectifier Diode Single 1.5 A 200 V DO-15 Through Hole STTH1R02QRL

Name: STMicroelectronics Silicon Junction Rectifier Diode Single 1.5 A 200 V DO-15 Through Hole STTH1R02QRL
Brand: STMicroelectronics
SKU: 211838
Price: 0.13 USD
Availability: InStock



Category Rectifier Diode Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Diameter	3.53mm
Brand	STMicroelectronics
Height	3.53mm
Length	6.75mm
Model	STTH1R02QRL
Width	3.53mm
Mount Type	Through Hole
Maximum Operating Temperature	175°C
Package Type	DO-15
Sub Type	Silicon Junction
Minimum Operating Temperature	-65°C
Pin Count	2
Diode Configuration	Single
Peak Non-Repetitive Forward Surge Current Ifsm	60A
Maximum Forward Voltage Vf	1.2V
Peak Reverse Recovery Time trr	30ns
Maximum Forward Current If	1.5A
Maximum Peak Reverse Repetitive Voltage Vrrm	200V

Key Features

Single silicon junction diode configuration for reliable rectification.
Maximum forward current of 1.5 A suitable for general purpose electronic applications.
Peak repetitive reverse voltage of 200 V ensures high voltage tolerance.
Through-hole mount DO-15 package with 2 pins for easy PCB installation.
Fast reverse recovery time of 30 nanoseconds enhances switching performance.
Operating temperature range from -65°C to 175°C supports harsh environments.
Peak non-repetitive forward surge current of 60 A allows handling transient conditions.
No automotive or special standards compliance, designed for industrial and electronic circuit use.

Product Description

STMicroelectronics STTH1R02QRL is a single silicon junction rectifier diode designed for use in electronic circuits requiring reliable forward current conduction and high reverse voltage blocking capability. It is packaged in a standard DO-15 through-hole package featuring 2 pins for straightforward PCB mounting.

This diode handles a maximum forward current of 1.5 amperes and withstands a maximum peak repetitive reverse voltage of 200 volts. The fast reverse recovery time of 30 nanoseconds makes it suitable for switching applications where rapid response is necessary. Its robust temperature tolerance from -65°C up to 175°C enables operation in demanding industrial and commercial environments.

The device supports transient surge currents up to 60 amperes non-repetitively, providing resilience against short voltage spikes or switching surges. Its compact size with a length of 6.75 mm and diameter of 3.53 mm allows integration into space-constrained electronic designs.

This Rectifier Diode is commonly used in power supply units, electronic control systems, and circuits requiring unidirectional current flow and over-voltage protection. While it does not meet automotive standards, it is widely applicable in industrial, manufacturing, and electronic component applications.

Single silicon junction diode configuration for consistent rectification performance. Rated maximum forward current of 1.5 A for standard electronic loads. Maximum peak reverse voltage of 200 V supports high voltage blocking.

Through-hole DO-15 package for easy soldering and mounting. Fast switching performance with a peak reverse recovery time of 30 ns. Wide operating temperature range from -65°C to 175°C. Capacity to handle 60 A peak surge current in transient conditions.

Compact physical dimensions suitable for various electronic designs. Designed for industrial and electronics applications requiring reliable rectification.
