RS PRO Pluggable Terminal Block 8-Contact 5 mm Pitch 1 Row 15A 450V Polyamide 66 Housing 144-4308

Free Delivery in India | Lowest Global Shipping Charges

RS PRO Pluggable Terminal Block 8-Contact 5 mm Pitch 1 Row 15A 450V Polyamide 66 Housing 144-4308

Name: RS PRO Pluggable Terminal Block 8-Contact 5 mm Pitch 1 Row 15A 450V Polyamide 66 Housing 144-4308
Brand: RS PRO
SKU: 211076



Category Pluggable Terminal Blocks Brand RS PRO Condition New

Specifications

Country of Origin	India
Voltage	450V
Brand	RS PRO
Colour	Green
Orientation	Straight
Current	15A
Length	40mm
Model	144-4308
Depth	18.1mm
Width	15.05mm
Housing Material	Polyamide 66
Number of Rows	1
Pitch	5mm
Number of Contacts	8
Minimum Wire Size mm²	0.32mm²
Maximum Wire Size mm²	1.6mm²
Minimum Wire Size AWG	28AWG
Maximum Wire Size AWG	14AWG
Wire Connection Method	Screw
RS PRO Pluggable Terminal Block, 8-Contact, 5 mm Pitch, 1 RowBrand	RS PRO

Key Features

The terminal block is made of green polyamide 66 housing providing UL94-V0 flame retardancy.
It supports wire sizes ranging from 0.32 mm² (28 AWG) to 1.6 mm² (14 AWG).
The connection method uses captive screws ensuring secure wire connections.
The block is oriented straight with guided pin alignment for ease of installation.
The compact dimensions are approximately 40 mm length, 15.05 mm width, and 18.1 mm depth.
Designed for industrial and electronic applications requiring reliable terminal connections.
UL and VDE approvals ensure compliance with international safety standards.
Suitable for modular multi-pole solid block assemblies with professional rising clamp terminals.

Product Description

RS PRO 144-4308 is a high-quality pluggable terminal block designed for electronic and industrial applications. This 8-contact block features a 5 mm pitch and a single row configuration, rated for currents up to 15A and voltages up to 450V, making it suitable for a wide range of electrical connectivity needs.

The terminal block housing is constructed from durable polyamide 66 material with UL94-V0 flame retardant properties, ensuring safety and longevity in demanding environments. The green coloration aids in easy identification within assemblies.

It supports wire sizes from 0.32 mm² (28 AWG) up to 1.6 mm² (14 AWG), accommodating both solid and stranded cables. The secure wire connection is provided by captive screws and professional rising clamp terminals. Guided pin alignment and polarised mouldings facilitate straightforward and reliable connection and disconnection.

With compact dimensions of approximately 40 mm length, 15.05 mm width, and 18.1 mm depth, this terminal block fits well in modular multi-pole solid block assemblies for electronic circuit boards and power distribution.

The product complies with UL and VDE standards although no specific standard numbers are provided, indicating adherence to recognized safety norms. This ensures suitability for industrial, manufacturing, laboratory, automation, and electrical applications.

The terminal block is made of green polyamide 66 housing providing UL94-V0 flame retardancy. It supports wire sizes ranging from 0.32 mm² (28 AWG) to 1.6 mm² (14 AWG). The connection method uses captive screws ensuring secure wire connections.

The block is oriented straight with guided pin alignment for ease of installation. The compact dimensions are approximately 40 mm length, 15.05 mm width, and 18.1 mm depth. Designed for industrial and electronic applications requiring reliable terminal connections.

UL and VDE approvals ensure compliance with international safety standards. Suitable for modular multi-pole solid block assemblies with professional rising clamp terminals. Explore a wide range of Pluggable Terminal Blocks and related connectors at EnvMart to find the perfect solution for your electrical and electronic component needs.
