TE Connectivity PCB Power Relay, 115V AC Coil, 12A Switching Current, SPDT RT114615
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Height | 15.7mm |
| Length | 29mm |
| Model | RT114615 |
| Width | 12.7mm |
| Mount Type | PCB |
| Contact Material | Silver Nickel Alloy |
| Series | RT1 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 12A |
| Terminal type | Through Hole |
| Standards/Approvals | IEC 60335-1, RoHS, VDE |
| Coil Resistance | 8.1kΩ |
| Coil Voltage | 115V ac |
| Switching AC Voltage | 400V ac |
| Coil Power | 250mW |
Key Features
- Operates with a coil voltage of 115V AC.
- Switching current capacity of 12 amperes.
- Single pole double throw (SPDT) contact configuration.
- Through hole mount type designed for PCB installation.
- Coil resistance of 8.1 kΩ ensuring efficient power usage.
- Rated switching AC voltage up to 400V AC.
- Coil power consumption of 250 mW.
- Wide operating temperature range from -40°C to 85°C.
Product Description
TE Connectivity RT114615 PCB Power Relay is a high-quality, through-hole mounted relay designed for PCB applications. It features a coil voltage of 115V AC and supports a robust switching current of 12A, which makes it ideal for demanding electrical control and automation tasks.
The relay utilizes a single pole double throw (SPDT) contact configuration, providing flexible and reliable switching capabilities. Its compact design with dimensions of 29mm length, 15.7mm height, and 12.7mm width allows space-efficient PCB mounting, suitable for industrial and domestic automation systems.
The coil resistance is 8.1 kΩ, and it operates with a low coil power of 250 mW, promoting efficient energy consumption. Rated for a switching AC voltage of up to 400V and designed to work over a temperature range from -40°C to 85°C, this relay is built to withstand diverse environmental conditions.
Constructed with durable silver nickel alloy contacts, it ensures longevity and reliable electrical connections. The product complies with IEC 60335-1, RoHS standards, and VDE certifications, demonstrating its quality and safety for professional use.
This relay is widely applicable in interface circuits, automation, security lighting, heating systems, and other industrial, laboratory, and commercial applications. It supports through-hole PCB mounting with flux-proof pins enhancing soldering reliability.
Operates with a coil voltage of 115V AC. Switching current capacity of 12 amperes. Single pole double throw (SPDT) contact configuration. Through hole mount type designed for PCB installation. Compact and robust dimensions with high reliability.
Low coil power consumption of 250 mW. Wide operating temperature range from -40°C to 85°C. Durable silver nickel alloy contact material. Standards compliant: IEC 60335-1, RoHS, VDE. Ideal for industrial and domestic automation and control applications.
Explore a wide range of industrial relays and power electronic components at EnvMart for your automation and electrical control needs.
Explore more products in our Power Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this power relay is 115V AC.
It has a maximum switching current capacity of 12 amperes.
This model utilizes a single pole double throw (SPDT) contact configuration.
The rated switching AC voltage for this relay is up to 400V AC.
The coil resistance is 8.1 kΩ, which promotes efficient power usage.
The dimensions of this relay are 29mm in length, 15.7mm in height, and 12.7mm in width.
The coil power consumption is 250 mW.
It operates within a wide temperature range from -40°C to 85°C.
The contacts are constructed from durable silver nickel alloy material.
This relay complies with IEC 60335-1, RoHS standards, and VDE certifications.
It is designed for through-hole mounting on a PCB.
This relay is applicable in interface circuits, automation, security lighting, and heating systems.
