TE Connectivity DIN Rail Power Relay 24V DC Coil 3A Switching Current SPST PCJ-124D3MH,301

TE Connectivity PCJ-124D3MH,301 is a miniature power relay designed for DIN Rail mounting, featuring a 24V DC coil and a switching current capacity of 3A in a Single Pole Single Throw (SPST) contact configuration. This compact relay measures 20.4mm in length, 14mm in width, and 15mm in height, making it suitable for space-constrained applications.

The relay is equipped with a highly sensitive coil consuming just 200mW, ensuring low power consumption. It is capable of switching both AC and DC voltages, with a maximum switching power of 750VA and supports switching of 30V DC and up to 400V AC loads.

Constructed with Class A silver-nickel contacts using silver alloy material, the relay offers excellent electrical conductivity and durability. Its operating temperature range from -40°C to +90°C allows reliable operation in harsh industrial environments.

This device uses through-hole terminal types providing secure and stable PCB mounting. The coil resistance is 2.9kΩ, optimizing the relay's sensitivity and efficiency. It is RoHS compliant, meeting environmental regulations for safe use in electrical and automation industries.

Typical applications include domestic appliances, industrial automation, and control systems requiring reliable power switching capabilities on DIN Rail platforms. The relay is designed for DIN Rail mounting ensuring easy installation.

Equipped with a sensitive coil consuming only 200mW for efficient operation. Offers a switching power capacity of 750VA suitable for medium power applications. Constructed with silver alloy contacts providing reliable conductivity.

Operates within a temperature range of -40°C to 90°C for durability. Compact dimensions: 20.4mm length, 14mm width, and 15mm height. Features through-hole terminals for secure PCB mounting. Compliant with RoHS standards ensuring environmental safety.

Designed for industrial and automation applications requiring robust Power Relays. Explore the TE Connectivity range at EnvMart for superior industrial electrical components supporting automation and control systems.
