MikroElektronika Sensor Development Tool ECG Click Bundle Heart Rate Sensor MikroBus Click Board MIKROE-2458

The MikroElektronika MIKROE-2458 ECG Click Bundle Sensor Development Tool is a precise accessory board designed to add electrocardiogram measurement capabilities to compatible development platforms. This board operates by measuring the electrical activity of the heart through three electrodes attached to the skin via a 3.5mm jack connector.

The ECG Click Board features a comprehensive 7-block design including protection circuitry, preamplifier stages, high-pass and low-pass filters, an amplifier, and a driven right leg (DRL) circuit. These features ensure that the electrical signals from the heart are accurately amplified and filtered to provide a clean, high-fidelity output signal for your development device.

This starter kit bundle includes the ECG Click Board itself, a 3-lead ECG cable with a 3.5mm jack, and 30 single-use ECG electrodes, making it ready for immediate use in biomedical sensor development projects. The board is powered by a 5 V supply and outputs an analog signal through the mikroBUS AN pin.

Users can adjust the output voltage range using onboard jumpers and fine-tune the signal gain via a trimmer potentiometer. The package is fully RoHS compliant and designed for developers working with MCUs that have at least a 10-bit ADC resolution.

For data visualization and analysis, the MikroPlot software provided by MikroElektronika can be used to generate ECG plots, facilitating easy interpretation of heart rate signals in various applications ranging from educational prototypes to biomedical research.

This ECG Click Bundle is ideal for industrial, laboratory, educational, and biomedical development use cases where accurate heart rate sensing is required. Its compatibility with the mikroBUS standard allows fast and flexible implementation in a wide range of embedded systems.

Designed to measure electrical activity of the heart using 3 electrodes connected via a 3.5mm jack. Includes ECG Click Board, 3 Lead ECG cable, and 30 single-use ECG electrodes for starter kit variant. Features 7-block design with protection, amplification, filtering, and a drl circuit for clear signal output.

Adjustable output voltage range and gain via jumpers and trimmer potentiometer. Supplies analog output through mikroBUS AN pin and requires 5 V power supply. Compatible with MikroElektronika MikroPlot software for ECG data visualization and analysis.

Plug-and-play solution fitting the popular mikroBUS socket for easy integration. Browse more Sensor Development Tools and biomedical boards at EnvMart for diverse applications and full product ranges from MikroElektronika.
