Relpol PCB Power Relay 12V DC Coil 15A Switching Current SPDT RM50-3011-85-1012

Free Delivery in India | Lowest Global Shipping Charges

Relpol PCB Power Relay 12V DC Coil 15A Switching Current SPDT RM50-3011-85-1012

Name: Relpol PCB Power Relay 12V DC Coil 15A Switching Current SPDT RM50-3011-85-1012
Brand: Relpol
SKU: 202486



Category Power Relays Brand Relpol Condition New

Specifications

Country of Origin	Poland
Brand	Relpol
Height	15.5mm
Length	19mm
Model	RM50-3011-85-1012
Width	15.4mm
Mount Type	PCB
Contact Material	Silver Alloy
Series	RM50
Maximum Operating Temperature	55°C
Contact Configuration	SPDT
Minimum Operating Temperature	-30°C
Switching Current	15A
Terminal type	PCB Pin
Contact Resistance	100mΩ
Standards/Approvals	RoHS
Coil Resistance	400Ω
Coil Voltage	12V dc
Switching DC Voltage	48V dc
Switching AC Voltage	48V ac
Coil Power	360mW

Key Features

Designed for general-purpose applications requiring reliable switching performance.
Features a compact size with dimensions 19mm length x 15.4mm width x 15.5mm height.
Coil power is 360mW with coil resistance of 400Ω ensuring efficient operation.
Suitable for switching AC and DC voltages up to 48V with switching power rating of 3kVA.
High contact quality using silver alloy with contact resistance of 100mΩ for durability.
Operates reliably in temperature range from -30°C to 55°C with high shock and vibration resistance.
PCB pin terminal type for secure and easy PCB mounting.
Compliant with RoHS standards ensuring environmental safety.

Product Description

Relpol RM50-3011-85-1012 PCB Power Relay offers robust and compact switching solution with 12V DC coil and 15A switching current in SPDT contact configuration. Engineered for PCB mounting, the RM50 series is ideal for use in various industrial, machine, automotive, and electronic equipment applications where reliable relay switching is essential.

This relay features a coil power consumption of 360mW and coil resistance of 400Ω, designed for efficient electromagnetic operation. It supports switching DC and AC voltages up to 48V and can handle switching power up to 3kVA, making it suitable for moderate power control circuits.

The compact dimensional footprint of 19mm x 15.4mm x 15.5mm allows for space-saving PCB layouts. The relay contacts use silver alloy material to ensure minimal contact resistance (100mΩ) and long operational life. Rated for operating temperatures between -30°C and 55°C, it withstands harsh environmental conditions including shocks and vibrations.

Relpol RM50 series power relays are certified RoHS compliant to meet environmental regulations. The PCB pin terminal type simplifies mounting and integration into printed circuit boards, supporting efficient assembly processes in manufacturing.

Designed for general-purpose switching in industrial and automotive applications. Compact miniature design ideal for PCB mounting. High switching current rating of 15A for reliable load handling. Low coil power consumption of 360mW for energy efficient operation.

Wide operating temperature range from -30°C to 55°C. Silver alloy contacts ensure durability and low contact resistance. PCB pin terminal for easy integration into electronic assemblies. Compliant with RoHS environmental standards.

This power relay is suitable for use in electrical automation systems, control equipment, and various electronic devices requiring dependable relay switching functions. It represents a precise and durable solution for a wide spectrum of control and switching applications within industrial, laboratory, and manufacturing settings.
