Texas Instruments 12-bit 8-Channel SAR Architecture ADC 500ksps 3.3V 16-Pin TSSOP ADC128S052CIMT/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 12 bit |
| Brand | Texas Instruments |
| Height | 1.2mm |
| Length | 5.4mm |
| Model | ADC128S052CIMT/NOPB |
| Mount Type | Surface |
| Sampling rate | 500ksps |
| Series | ADC128S052 |
| Input Type | Voltage |
| Maximum Operating Temperature | 105°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Interface Type | QSPI, Microwire, SPI |
| Architecture | SAR |
| Pin Count | 16 |
| Automotive Standard | AEC-Q100 |
| Minimum Supply Voltage | 3.3V |
| Number of ADCs | 8 |
Key Features
- The device features successive approximation register (SAR) architecture for precise analog-to-digital conversion.
- It supports 8 ADC channels with 12-bit resolution suitable for multi-channel applications.
- The ADC operates with a minimum supply voltage of 3.3V, ensuring low power consumption.
- Compatible with QSPI, Microwire, and SPI interface types for flexible connectivity.
- Designed for operation in extreme temperature ranges from -40°C to 105°C.
- Compact form factor with length 5.4mm and height 1.2mm, ideal for surface mount applications.
- Complies with AEC-Q100 automotive standard for reliability in critical environments.
- Ideal for use in industrial, automotive, and laboratory instrumentation.
Product Description
Texas Instruments ADC128S052CIMT/NOPB is a high-performance 12-bit analog-to-digital converter (ADC) featuring 8 input channels and SAR architecture, delivering a sampling rate of 500ksps. Packaged in a compact 16-Pin TSSOP, it supports low voltage operation starting from 3.3V, making it suitable for power-sensitive designs.
Engineered to operate across a wide temperature range from -40°C to 105°C, this ADC meets the AEC-Q100 automotive standard, ensuring high reliability for automotive and industrial applications. The device offers versatile interface compatibility including QSPI, Microwire, and SPI protocols facilitating ease of integration into various microcontroller and embedded systems.
With precise 12-bit resolution and multi-channel capability, the ADC128S052CIMT/NOPB is ideal for applications such as sensor data acquisition, signal processing, and instrumentation in laboratory, industrial, and automotive contexts.
The compact dimensions of 5.4mm length and 1.2mm height make it suitable for space-constrained PCB layouts requiring surface mount technologies. The SAR architecture ensures fast and accurate conversion performance. Supports up to 8 input channels for multi-sensor interfacing.
Wide operating temperature suits harsh environments and automotive use. Low operating voltage reduces power consumption in battery-operated devices. Flexible SPI, QSPI, and Microwire interfaces enable diverse communication options.
Complying with automotive-grade standards enhances suitability for safety-critical designs. Compact TSSOP package allows dense PCB integration. Optimized for precision industrial control and measurement systems. For comprehensive product options and technical support, explore Texas Instruments products and industrial-grade analog to digital converters on EnvMart.
Explore more products in our Analogue to Digital Converter category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ADC128S052CIMT/NOPB features a resolution of 12 bits.
It has a maximum sampling rate of 500ksps.
The operating temperature range is from -40°C to 105°C.
It supports QSPI, Microwire, and SPI interface types for flexible connectivity.
The minimum supply voltage required is 3.3V.
This model supports 8 input channels.
The dimensions are 5.4mm in length and 1.2mm in height.
It is designed for surface mount applications.
The device complies with the AEC-Q100 automotive standard.
It features a successive approximation register (SAR) architecture.
It is suitable for applications in industrial, automotive, and laboratory instrumentation.
The input type is voltage.
