RS PRO Circular Connector, 5 Contacts, Flange Mount, Socket Female, IP68, 10A, 500V, Threaded Mating, Polyamide 66 124-6679
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 500V |
| Brand | RS PRO |
| Orientation | Straight |
| Current | 10A |
| Model | 124-6679 |
| IP Rating | IP68 |
| Mount Type | Flange |
| Housing Material | Polyamide 66, Polycarbonate |
| Contact Material | Brass |
| Series | RS PRO |
| Termination Type | Screw |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Pole Format | 5 |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Female |
| Shell Size | 21 mm |
| Mating Type | Threaded |
| Connector Size | Standard |
| Plug/Socket | Socket |
| Cable outer diameter acceptance | 4.5 mm - 7 mm |
| Panel hole cutout diameter | 21 mm |
Key Features
- The connector features a robust polyamide 66 and polycarbonate housing for durability.
- The gold-plated brass contact ensures reliable electrical connections.
- Screw termination type provides secure cable attachment.
- Mount type is flange with a panel hole cutout diameter of 21 mm.
- Operating temperature ranges from -40°C to 85°C for versatile industrial use.
- Cable outer diameter acceptance ranges between 4.5 mm and 7 mm.
- The connector is a female socket with a threaded mating type and straight orientation.
- Designed to meet industrial requirements without specific standards or approvals.
Product Description
RS PRO 124-6679 Circular Connector is a high-performance industrial component featuring 5 contacts and a flange mount socket design. Rated IP68, it offers excellent resistance against dust and water ingress, making it ideal for harsh operating environments. This connector supports a maximum current of 10A at 500V, making it suitable for various electronics and power connector applications.
The housing is made from durable polyamide 66 and polycarbonate materials, ensuring long service life and structural integrity. The contacts, made of brass with gold plating, guarantee reliable conduction and corrosion resistance. Screw termination type allows secure and stable cable connections, accommodating cables with outer diameters from 4.5 mm to 7 mm.
Mounting is achieved via a 2-hole flange with a panel cutout size of 21 mm, facilitating straightforward installation on panels. Its operating temperature range of -40°C to 85°C covers a wide variety of industrial environments. The connector’s straight orientation and threaded mating type ensure compatibility with corresponding components while providing secure locking.
This female socket connector from the RS PRO series is engineered without specific approvals but meets rigorous industrial requirements. It excels in applications in industrial tools, power connectors, and electronics, offering dependable electrical connections under demanding conditions.
The connector features a robust polyamide 66 and polycarbonate housing for durability. The gold-plated brass contact ensures reliable electrical connections. Screw termination type provides secure cable attachment. Mount type is flange with a panel hole cutout diameter of 21 mm.
Operating temperature ranges from -40°C to 85°C for versatile industrial use. Cable outer diameter acceptance ranges between 4.5 mm and 7 mm. The connector is a female socket with a threaded mating type and straight orientation.
Designed to meet industrial requirements without specific standards or approvals. This IP68 rated connector is suitable for harsh environments requiring dust-tight and water-resistant performance. Perfect for industrial electrical, power connectors, and electronics applications.
For professionals seeking reliable circular connectors, the RS PRO 124-6679 offers a dependable solution. Explore the RS PRO brand and Industrial Circular Connectors category on EnvMart for a variety of compatible products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this connector is 10A.
This model is rated for a maximum voltage of 500V.
The connector has an IP68 rating, indicating it is dust-tight and resistant to water ingress.
The housing is made from polyamide 66 and polycarbonate materials.
It operates within a temperature range of -40°C to 85°C.
The required panel hole cutout diameter for this connector is 21 mm.
This connector uses a screw termination type for secure cable attachment.
It accepts cables with an outer diameter ranging from 4.5 mm to 7 mm.
This model features 5 contacts.
The connector has a straight orientation.
It uses a threaded mating type for secure connections.
The contacts are made of brass with gold plating for reliable electrical conduction.
