RS PRO Circular Connector 2 Contacts Front Mount Standard Size Socket Female IP68 500V 10A 124-6671

RS PRO 124-6671 Circular Connector is a 2 contact, front mount, standard size socket featuring female contact gender and is rated IP68 for dust and water ingress. It operates at 500V and supports 10A current, making it suitable for demanding industrial and electronic applications.

The connector incorporates a sturdy polyamide 66 and polycarbonate housing with gold-plated brass contacts to ensure reliable electrical performance and longevity. It features a threaded mating type that provides a secure and stable connection in industrial environments.

The termination type is screw-based, suitable for cables with outer diameters from 4.5 mm to 7 mm, and the panel cutout diameter is 21 mm for proper mounting. This connector is designed for front mounting with a straight orientation, facilitating easy installation in panels or equipment.

Operating temperature ranges from -40°C to 85°C, supporting reliable function in harsh temperature conditions. The IP68 rating certifies its protection against dust ingress and water immersion, making it ideal for external, industrial, and heavy-duty applications.

Key features include its high-quality shell materials, gold-plated contacts for optimal conductivity, and compatibility with various industrial setups such as manufacturing lines, electronic equipment, power distribution systems, and heavy machinery connections. The robust design ensures long-term stability and performance even in challenging environments.

Features threaded mating type ensuring secure connection. Current rating of 10A and voltage rating of 500V suitable for power applications. Constructed with polyamide 66 and polycarbonate housing materials for durability.

Gold-plated brass contacts provide excellent conductivity and corrosion resistance. Suitable for cable outer diameter 4.5 mm to 7 mm with screw termination type. Panel hole cutout diameter is 21 mm for installation compatibility.

Operates reliably within temperature range of -40°C to 85°C. Front mount with straight orientation for ease of installation. IP68 rated for protection against dust and water ingress in harsh environments. Ideal for industrial, manufacturing, and electronic power connector uses.

Explore more Industrial Circular Connectors from RS PRO on EnvMart to find the perfect fit for your electronic and power connection needs.
