Siemens SENTRON Miniature Circuit Breaker, 2-Pole, 13A, Type B, 400V AC, 60V DC, 6kA Breaking Capacity 5SJ6513-6KS

Siemens 5SJ6513-6KS SENTRON Miniature Circuit Breaker is a high-quality 2-pole protective device rated at 13 amperes with Type B tripping characteristic. It is designed for use in electrical installations to protect lighting and socket outlet circuits against overload and short circuit faults. The circuit breaker supports both AC and DC applications with a rated voltage of 400V AC and 60V DC.

This MCB features screwless terminals for quick and secure wiring, allowing connection of rigid wires from 1 to 4mm² and flexible wires from 1 to 2.5mm² without requiring end sleeves. The unit easily mounts on standard DIN rails and offers touch protection conforming to IP20 standards, ensuring safety during handling and operation.

With a robust breaking capacity of 6kA, this Siemens SENTRON breaker reliably interrupts fault currents to prevent damage to electrical systems. Dimensions are compact at 90mm height, 36mm width, and 76mm depth, making it suitable for integration within various panel configurations.

The product fully complies with key international standards EN 60898 and IEC 60947-2, assuring dependable industrial and commercial usage. It is ideal for applications across residential, commercial, and light industrial sectors requiring efficient circuit protection.

2 poles with screwless terminals for easy and secure connections. Rated current capacity of 13 amperes for circuit protection. Type B tripping characteristic suitable for lighting and socket circuits. High breaking capacity of 6 kiloamperes ensuring reliable fault interruption.

Mounts easily on DIN rail with IP20 touch protection rating. Compact dimensions of 90mm height, 36mm width, and 76mm depth. Complies with EN 60898 and IEC 60947-2 standards for safety and performance. Double screwless outgoing terminals accommodate rigid and flexible conductors without the need for end sleeves.

Compatible with all Siemens 5SJ and 5SY miniature circuit breaker ranges.

This Miniature Circuit Breaker is suitable for industrial, commercial, residential, and electrical automation applications. It is part of the trusted Siemens SENTRON 5SJ6 series, known for quality and performance. Discover more Siemens electrical protection solutions and circuit breakers on EnvMart.
