Global Laser Modulating Red Laser Module 650nm 1mW TTL Control Dot Pattern 3V-6V 1260-03-000

Global Laser 1260-03-000 is a modulating laser module specifically designed for industrial and electronic component applications. This laser module emits red light at a wavelength of 650 nm with an optical output power of 1 mW, suitable for precision measurement and alignment tasks.

Equipped with TTL control input, the module supports rapid switching and gated operation with speeds up to 100 kHz, helping to minimize power consumption and prolong laser lifespan. Controlled chopping allows for true ON/OFF pulsed control and low-speed enable input for versatile use.

The laser is built into an isolated metal case with an M12 thread, measuring 24 mm in diameter and 14 mm in length, enabling simple thread mounting in various industrial setups. Its user-focusable spot size is less than 50 microns, and divergence is under 0.5 mRad, which allows for precise targeting and minimal beam spread.

The module runs continuously with efficient cooling properties and supports a supply voltage range from 3V to 6V. It is rated as Laser Class 2 and complies with BS (EN) 60825 standards to ensure safe operation when used properly. The operational temperature range is from -10°C to 40°C, allowing reliable function in different environmental conditions.

This unit is ideal for integration in laboratory equipment, industrial automation systems, electronic devices, and other applications requiring a compact, reliable laser source with modulation capabilities. The Cameo series design also features a JST 4-way connector for ease of installation.

Operates at 650 nm wavelength with 1 mW output power. TTL input enables high-speed modulation and energy efficiency. Compact metal housing with thread mounting simplifies installation. Low divergence and small spot size provide high precision.

Complies with BS (EN) 60825 laser safety standards. Operating temperature from -10°C to 40°C for industrial robustness. Suitable for electronics, industrial, laboratory, and measurement systems. Explore more industrial Laser Modules and optoelectronic components in the Electronics & Electricals category at EnvMart.
