Amphenol Limited MIL Spec Circular Connector Brass Straight 3 Way Wall Mount Female, Olive Drab Cadmium 97B-3100A-22-2S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 900V ac |
| Brand | Amphenol Limited |
| Colour | Olive |
| Orientation | Straight |
| Current | 46A |
| Model | 97B-3100A-22-2S |
| Mount Type | Wall Mount |
| Housing Material | Aluminium Alloy |
| Contact Material | Brass |
| Series | 97B |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Silver |
| Number of Contacts | 3 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shell Size | 22 |
| Military Standard | MIL-DTL-5015 |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Shell Plating | Olive Drab Cadmium |
Key Features
- Constructed with brass contacts and aluminium alloy housing for enhanced durability.
- Rated for 900V AC voltage and 46A current capacity ensuring high performance.
- Features olive drab cadmium plating for corrosion resistance.
- Wall mount type with bayonet mating and straight orientation.
- Operates reliably between -55°C and 125°C temperature range.
- Designed according to MIL-DTL-5015 military standard for rugged applications.
- Contact gender is female with solder termination type for secure connections.
- Includes strain relief and a standard shell size 22 for easy integration.
Product Description
Amphenol Limited 97B-3100A-22-2S MIL Spec Circular Connector is a high-quality brass straight 3-way wall mount connector designed for industrial and military use. It features a female contact configuration with a female connector gender, ideal for secure and space-efficient panel mounting applications requiring reliable electrical connections.
This MIL-C-5015 bayonet lock connector meets MIL-DTL-5015 standards and is constructed with an aluminium alloy housing plated with olive drab cadmium for corrosion resistance. The connector supports a voltage rating of 900V AC and current capacity of 46A, making it suitable for demanding electrical environments.
The solder termination type ensures secure contact mounting of the brass contacts plated with silver over nickel, combined with a polychloroprene insulator to maintain electrical insulation integrity. The device operates effectively within a wide temperature range from -55°C to 125°C, supporting harsh environmental conditions.
The wall mount design includes strain relief and a standard shell size 22, accommodating compatibility with MS/aN fittings. The 3-contact 97B series connector is widely used in aerospace, military, industrial, and watercraft electrical systems requiring robust, reliable circular connectors.
Brass contacts with silver plating ensure efficient conductivity. Olive drab cadmium plated aluminium alloy housing enhances corrosion resistance. Bayonet locking system provides secure connections. Suitable for MIL-DTL-5015 applications and interconnectable with BS 9522 F0032 connectors.
Designed for durable performance under temperature extremes and mechanical stress. Standard shell size 22 fit supports common industry usage. Includes strain relief for cable protection and longevity.
This connector is manufactured in India and is supplied in new condition, meeting stringent industrial quality standards. It is ideal for electronic components, power & connectors segments requiring Mil Spec Circular Connectors.
Explore more connectors and related accessories within the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector is rated for 900V AC voltage, making it suitable for high-performance electrical applications.
It has a current capacity of 46A, ensuring it can handle demanding electrical loads.
This model operates reliably within a temperature range of -55°C to 125°C, suitable for harsh environmental conditions.
The connector features brass contacts and an aluminium alloy housing, providing enhanced durability and corrosion resistance.
It utilizes a solder termination type, ensuring secure contact mounting for reliable connections.
The connector has a standard shell size of 22, accommodating compatibility with MS/aN fittings.
It is designed for wall mount applications, facilitating easy integration into various setups.
The connector features a female contact configuration, which is ideal for secure panel mounting applications.
It is designed according to the MIL-DTL-5015 military standard, ensuring it meets rigorous performance requirements.
It employs a bayonet mating type, providing secure connections in various applications.
The connector is manufactured in India, adhering to stringent industrial quality standards.
The housing is plated with olive drab cadmium, enhancing its corrosion resistance for durability in various environments.
