Schneider Electric Preventa Series Output Module, 4 Inputs, 12 Outputs, 24V DC, Power Rating 3W XPSMCMRO0004DA

Schneider Electric XPSMCMRO0004DA Preventa Series Output Module is a high-reliability safety IO module designed for industrial and process control applications requiring stringent safety standards. Operating at 24V DC with a low power rating of 3W, this output module provides 4 inputs and 12 outputs configured as forcibly guided contact safety relay outputs. Its compact size of 22.5 x 99 x 114.5 mm allows for easy installation within standard control cabinets.

This output module is specifically designed for use with the Preventa Modular Safety Controller and mounts securely on DIN Rails. It features removable screw-type terminal blocks to simplify wiring and maintenance tasks, while the relay outputs ensure Category 1, 2, and 4 safety architecture configurations, complying with relevant international safety standards including EN/ISO 13849-1 and IEC/EN 61508 SILCL 3.

The module includes 4 independent safety relay outputs and accompanying inputs used for external feedback contacts and device monitoring functions such as the Start/Restart interlock and EDM (External Device Monitoring). Its design excludes the need for an expansion bus connector since the relays connect directly to the selected OSSDs, enhancing reliability and reducing installation complexity.

The product is CE marked and certified by cULus and TUV for industrial safety applications. Additionally, this green premium product is RoHS compliant, reflecting an environmentally responsible design.

Typical use cases for the XPSMCMRO0004DA include industrial automation safety systems, manufacturing process controls, and other applications where Safety IO Modules must meet high performance and certification requirements. Its reliable construction and compact form factor make it suitable for deployment in laboratories, manufacturing plants, HVAC systems, and agricultural machinery control systems.

The module is designed for use with the Preventa Modular Safety Controller. Mounts easily on a DIN Rail for secure installation. Equipped with screw-type terminal blocks for reliable connections. Offers compliance with cULus safety standards for assured performance.

Compact dimensions of 22.5 x 99 x 114.5 mm for space-saving integration. Includes forcibly guided contact safety relays supporting Category 1, 2, and 4 architectures. Designed with removable terminal blocks simplifying wiring and maintenance.

Green premium product that is RoHS compliant, ensuring environmental safety. Does not require an expansion bus connector; relays are directly wired to OSSDs. Supports external device monitoring including Start/Restart interlock and EDM functions.
