ETA Thermal Circuit Breaker 1-Pole 1.5A Current Rating DIN Rail Mount 2210-T210-K0M1-H121-1.5A

ETA 2210-T210-K0M1-H121-1.5A is a high-quality thermal circuit breaker designed for industrial, automation, and electrical applications. It features a single-pole configuration with a 1.5A current rating suitable for precise overload and short circuit protection in process control, telecommunications, and other professional uses.

This circuit breaker utilizes a reliable thermal magnetic tripping mechanism with a medium break time, ensuring effective protection for electrical circuits. The device is mounted on a DIN rail with a narrow 12.5mm width and 29.6mm height, enabling dense and space-saving installations.

Equipped with a toggle switch reset actuator, the breaker allows easy manual resetting after tripping. Its compatibility with Top-hat and G-profile DIN rails as well as modular DIN 43880 housings increases installation flexibility. The breaker supports rated AC voltage up to 480V and DC voltage up to 65V, with a breaking capacity of 25A ensuring safe interruption of fault currents.

An auxiliary normally closed (NC) contact provides remote signalling capability to indicate the breaker status during operation. The breaker conforms to RoHS and CE standards and holds international approvals including UL, CSA, and VDE, reflecting its build quality and reliability.

Typical applications include precision electronic equipment protection, industrial machinery safety, telecom equipment safeguard, and process control systems requiring timed-delay trip operations.

Provides overload and short circuit protection for precision applications. Equipped with thermal magnetic tripping mechanism with medium break time. Features a toggle switch reset actuator for easy manual reset. Compact 12.5mm width and 29.6mm height narrow profile design.

Compatible with Top-hat and G-profile DIN rails and modular DIN 43880 housings. Rated AC voltage of 480V and DC voltage of 65V with 25A breaking capacity. Includes auxiliary NC contact for remote break status signalling.

Manufactured in Germany with RoHS and CE compliance. Explore more products in the Thermal Circuit Breaker category at EnvMart for a wide selection of industrial and electrical safety devices.
