SMC Pneumatic Solenoid Valve 5/2 Solenoid G SY5000 Series 24V DC Die Cast Aluminium Body

SMC SY7120-5DO-C10F-Q Pneumatic Solenoid Valve 5/2 Solenoid G SY5000 Series 24V DC offers precise and reliable pneumatic control with a robust die cast aluminium body. Designed for industrial, manufacturing, and automation applications, this valve ensures efficient solenoid actuation and fluid control.

Operating at a voltage of 24V DC and featuring a solenoid power consumption of just 0.35W, it is energy efficient while providing dependable actuation. The valve supports a maximum operating pressure of 0.7 MPa and a maximum flow rate of 863.7 NL/min, making it suitable for demanding pneumatic systems.

The valve function is 5/2 with five ports, enabling versatile pneumatic circuit configurations. Connection thread standard is G with an M5 port size, complemented by a DIN connector for electrical interface and DIN mount pattern for mechanical installation. The compact dimensions of 117.1 mm length, and 49 mm width and height allow seamless integration into pneumatic setups.

Seal material is Nitrile Rubber (NBR), providing reliable sealing and enhanced resistance to wear. The valve is designed to operate safely within temperatures ranging from -10°C to 50°C, ensuring performance stability in diverse environments. It is manufactured in France under stringent quality standards, with no hazardous area certification or special approvals.

This solenoid valve is ideal for industrial pneumatic control in assembly lines, fluid power management, automation systems, and laboratory equipment. Its low power consumption and durable construction contribute to efficient and continuous operation across various sectors.

Operates up to 0.7 MPa maximum pressure ensuring robust pneumatic control. Die cast aluminium body for strength and lightweight design. Nitrile Rubber (NBR) seals for reliable leak prevention and durability. Compact size and DIN standard mount and connector for easy installation.

Energy-efficient 0.35W solenoid power consumption supports cost-effective usage. Designed for a temperature range of -10°C to 50°C to suit multiple environments. 5 ports and 5/2 valve function enable versatile pneumatic circuit configurations.

Manufactured in France with high quality control standards. Explore a wide selection of Pneumatic Solenoid Valves and industrial valves on EnvMart to find compatible components and accessories to complete your system.
