SMC Pneumatic Guided Cylinder MGQ Series Double Acting Direct Mount 25 mm Stroke EMGQM32-25

SMC EMGQM32-25 Pneumatic Guided Cylinder MGQ Series is a compact and precise pneumatic actuator designed for industrial use, featuring a 25 mm stroke and double acting functionality. It is engineered to withstand very high radial loads, maintaining superior non-rotational accuracy through its guided slide and ball bearings.

The cylinder is equipped with rubber cushions at both ends to minimize impact and vibration during operation, enhancing durability and smooth performance. It operates reliably in temperatures ranging from -10°C up to 60°C and can handle a maximum operating pressure of 1 MPa, making it suitable for diverse pneumatic applications.

Designed with a direct mount type, the cylinder allows for easy installation and secure fixing on both sides. The single rod type construction simplifies attachment and maintenance processes. Additionally, the cylinder body is fitted with sensors that provide magnetic sensing capabilities, enabling precise position detection for automation control.

Materials and design allow for use with both lubricated and unlubricated air environments, expanding operational flexibility in industrial, manufacturing, and fluid power systems. The compact build and a gross weight of 1.5 kg support ease of integration in machinery without adding excessive load.

This MGQ series pneumatic guided cylinder is ideal for applications requiring high precision, resistance to side loads, and compact form factors, including construction machinery, automation equipment, and robotic actuators.

The cylinder features rubber cushioning at both ends for smooth operation. Guide type combines slide bearing and ball bearing for excellent non-rotational accuracy. Suitable for use with lubricated or non-lubricated air.

Operates effectively within temperature range from -10°C to 60°C. Designed for a maximum operating pressure of 1 MPa. Compact size with a gross weight of 1.5 kg for easy installation. Includes magnetic sensing capabilities with sensors fitted in the cylinder body.

Fixings are provided on both sides to facilitate direct mounting. Explore the extensive range of Pneumatic Guided Cylinders from SMC at EnvMart for reliable industrial pneumatic solutions.
