Schneider Electric Residual Current Circuit Breaker with Overload Protection 10A Current Rating 1-Pole 30 mA Trip A9DQ2610

Schneider Electric A9DQ2610 Residual Current Circuit Breaker with Overload Protection is designed for reliable electrical circuit protection in residential, distribution, and overcurrent applications. This 1-Pole RCBO features a 10A current rating and 30 mA trip sensitivity to detect earth leakage currents effectively.

The device employs thermal magnetic tripping technology, providing instantaneous protection against overloads and short circuits. Mounting is standardized for DIN Rail fitting, simplifying installation in electrical panels.

Constructed to meet EN/IEC 60947-2 and RoHS compliance, this breaker ensures both performance and environmental standards. Its compact form factor with a width of 36mm, height of 85mm, and depth of 73mm allows for efficient use of panel space.

Operational features include a toggle switch actuator with ON/OFF and trip indication, making it user-friendly and easily serviced. With a high breaking capacity of 6kA, it is suitable for various electrical distribution settings.

The breaker offers earth leakage protection rated as A-SI type, enhancing safety by mitigating electric shock risks. It is capable of operating in ambient temperatures ranging from -5 to 60 degrees Celsius and relative humidity levels up to 95% at 55 degrees Celsius, ensuring reliable functionality in diverse environmental conditions.

Additional durability is assured through an impulse withstand voltage of 4 kV and electrical endurance rated for 20,000 cycles. The padlockable design feature provides an extra layer of security against inadvertent or unauthorized switching.

Features thermal magnetic tripping mechanism for precise overload and short circuit protection. Mounts conveniently on DIN Rail for easy installation. Complies with EN/IEC 60947-2 and RoHS standards ensuring quality and safety.

Compact dimensions of 36mm width, 85mm height, and 73mm depth for space-saving integration. Toggle switch actuator with ON/OFF and trip indicator for user-friendly operation. Provides breaking capacity up to 6kA suitable for residential and distribution applications.

Earth leakage protection type A-SI enhances safety against electric faults. Designed for ambient operation between -5 to 60 °C and relative humidity up to 95% at 55 °C. Impulse withstand voltage of 4 kV ensures durability in demanding electrical environments.

Padlockable feature adds extra protection to prevent unauthorized operation.

Schneider Electric’s A9DQ2610 is a premium-class product from the Acti9 series combining safety, reliability, and compact design for industrial, residential, and commercial electrical circuit protection needs. Browse the Electronics & Electricals category on EnvMart for similar high-quality circuit protection devices.
