Schneider Electric Residual Current Circuit Breaker with Overload Protection, 20A Current Rating, 1-Pole, 30 mA Trip A9DP2620
Specifications
| Country of Origin | France |
|---|---|
| Range | Acti9 |
| Brand | Schneider Electric |
| Height | 85mm |
| Model | A9DP2620 |
| Depth | 73mm |
| Width | 36mm |
| Mount Type | DIN Rail |
| Current Rating | 20A |
| Series | ACTI9 iDD40T XA |
| Terminal type | Tunnel |
| Breaking Capacity | 6kA |
| Number of Poles | 1 |
| Standards/Approvals | EN/IEC 60947-2, RoHS |
| Rated AC Voltage | 230V ac |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Trip Sensitivity | 30mA |
| Earth Leakage Protection Type | AC |
Key Features
- Features thermal magnetic tripping mechanism for effective short circuit and overload protection.
- Compact DIN Rail mount type ensuring easy installation and integration.
- Rated for 230V AC voltage with 6kA breaking capacity for robust performance.
- Equipped with toggle switch actuator for quick reset and operation.
- Adheres to EN/IEC 60947-2 and RoHS standards ensuring compliance and quality.
- Designed with 36mm width and 85mm height occupying minimal panel space.
- Incorporates AC type earth leakage protection with 30mA trip sensitivity.
- Impulse withstand voltage up to 4 kV enhancing durability under electrical stress.
Product Description
Schneider Electric A9DP2620 Residual Current Circuit Breaker with Overload Protection is engineered for precise circuit safeguarding in residential and light commercial electrical distribution systems. Featuring a 20 ampere current rating and single pole configuration, this RCBO ensures protection against overcurrent, short circuits, and earth leakages with a trip sensitivity of 30 mA.
This device integrates thermal magnetic tripping technology to provide reliable and swift response during fault conditions, minimizing electrical hazards. The unit is intended for DIN Rail mounting, streamlining installation within electrical panels.
Rated at 230V AC and supporting a breaking capacity of 6 kiloamperes, it suits a wide range of applications requiring efficient overcurrent and leakage protection. The toggle switch actuator combined with ON/OFF and trip indicator enables easy manual operation and status monitoring.
Certified to meet EN/IEC 60947-2 and RoHS standards, this Schneider Electric RCBO guarantees compliance with international safety and environmental norms. The compact form factor with dimensions of 36mm width, 85mm height, and 73mm depth allows optimized panel space usage.
Its impulse withstand voltage rating of 4 kV and an operational ambient temperature range from -5°C to 60°C ensure durability and reliable performance in diverse industrial and residential environments. Additionally, the padlockable design enhances safety by preventing unauthorized activations.
Features thermal magnetic tripping mechanism for overcurrent and short circuit protection. Designed for DIN Rail mounting for straightforward installation. Rated AC voltage: 230V with a breaking capacity of 6 kA for circuit reliability.
Toggle switch reset actuator with ON/OFF and trip indication. Complies with EN/IEC 60947-2 and RoHS certifications. Compact dimensions of 36mm x 85mm x 73mm for panel efficiency. Earth leakage protection type AC with 30mA trip sensitivity.
Padlockable mechanism for enhanced operational safety.
This Residual Current Circuit Breaker is ideal for use in electrical distribution, residential installations, and industrial applications requiring guaranteed earth leakage and overcurrent protection. Its robust design and reliability make it suitable for construction, HVAC systems, manufacturing plants, and water treatment facilities.
Explore more high-quality circuit protection solutions from Schneider Electric and other leading brands in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 20A.
It has a breaking capacity of 6kA, suitable for reliable circuit protection.
The rated AC voltage for this circuit breaker is 230V.
This model utilizes a thermal magnetic tripping mechanism for effective protection against overcurrent and short circuits.
It incorporates AC type earth leakage protection with a trip sensitivity of 30mA.
The dimensions are 36mm in width, 85mm in height, and 73mm in depth.
This unit is designed for DIN Rail mounting, facilitating straightforward installation.
It adheres to EN/IEC 60947-2 and RoHS standards, ensuring compliance with safety and environmental regulations.
The operational ambient temperature range is from -5°C to 60°C.
Yes, it features a toggle switch reset actuator with ON/OFF and trip indication for easy operation.
This circuit breaker is a 1-pole configuration.
It belongs to the ACTI9 iDD40T XA series.
