Amphenol Communications Solutions Bergstik Series Vertical Through Hole Pin Header 4 Contacts 2.54 mm Pitch 2 77313-124-04LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1500V |
| Brand | Amphenol Communications Solutions |
| Orientation | Vertical |
| Current | 3A |
| Model | 77313-124-04LF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Phosphor Bronze |
| Termination Type | Solder |
| Maximum Operating Temperature | 130°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Standards/Approvals | UL Approval:E66906 |
| Contact Plating | Phosphor Bronze |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
| Standards/ApprovalsUL Approval | E66906 |
| UL Approval | E66906 |
Key Features
- Constructed with thermoplastic housing for durability.
- Phosphor bronze contact and plating ensure excellent conductivity.
- Suitable for operating temperatures between -65°C and 130°C.
- Designed with 2 rows, vertical orientation, and unshrouded pins for easy soldering.
- Supports 3A current with 1500 V voltage rating for versatile applications.
- Tail pin length of 2.9 mm and mating pin length of 6.75 mm for secure connections.
- UL approval (E66906) guarantees safety and compliance.
- Ideal for mezzanine applications and variable stacking heights.
Product Description
Amphenol Communications Solutions 77313-124-04LF Bergstik Series Vertical Through Hole Pin Header is designed for reliable board-to-board, wire-to-board, and cable-to-board interconnect solutions. Featuring 4 contacts spaced at 2.54 mm pitch across 2 rows, this connector provides robust electrical performance with a 3A current rating and 1500V voltage handling capability.
The pin header is constructed with high-temperature thermoplastic housing that withstands operating temperatures from -65°C up to 130°C, suitable for demanding environments. Phosphor bronze contact material and plating ensure excellent conductivity and durability.
It is unshrouded and vertically oriented, facilitating easy through-hole mounting and soldering techniques. Tail pin length of 2.9 mm and mating pin length of 6.75 mm optimize mechanical retention and connectivity.
This component is UL approved (E66906) ensuring compliance with safety standards. Its design allows dual entry, enabling mating from top or bottom, suitable for mezzanine and stacking header applications, offering flexible stack height options.
Constructed with thermoplastic housing for durability. Phosphor bronze contact and plating ensure excellent conductivity. Operates within a temperature range of -65°C to 130°C. Supports 3A current and 1500V voltage for reliable performance.
2 row, 4 contact vertical unshrouded design for through-hole mounting. Tail pin length of 2.9 mm and mating pin length of 6.75 mm for secure connections. UL approval with E66906 certification for safety compliance. Ideal for mezzanine and stacking header applications requiring variable stacking heights.
This pin header is widely used in electronics manufacturing, communication devices, industrial automation, and other electrical applications requiring compact and durable PCB connectors.
Explore more high-quality PCB connectors and electronic components at EnvMart to meet your design and production needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 3A, making it suitable for various electrical applications.
This model has a voltage rating of 1500V, ensuring reliable performance in high-voltage applications.
The contacts are spaced at a pitch of 2.54 mm, allowing for standard PCB layouts.
The tail pin length is 2.9 mm, while the mating pin length is 6.75 mm, optimizing mechanical retention.
It operates within a temperature range of -65°C to 130°C, suitable for demanding environments.
The housing is constructed from thermoplastic, providing durability for various applications.
Yes, it has UL approval (E66906), ensuring compliance with safety standards.
It uses a solder termination type, facilitating secure connections during assembly.
This model features 4 contacts, arranged in 2 rows for efficient connectivity.
It has a vertical orientation, which allows for easy through-hole mounting.
It is ideal for mezzanine applications and variable stacking heights, commonly used in electronics manufacturing and communication devices.
The contacts are made of phosphor bronze, which ensures excellent conductivity and durability.
