Amphenol Communications Solutions Bergstik Series Vertical Through Hole Pin Header 9 Contacts 2.54 mm Pitch 1 77311-118-09LF

Amphenol Communications Solutions 77311-118-09LF Bergstik Series pin header is a vertical, through hole PCB connector featuring 9 male contacts arranged in a single row with 2.54 mm pitch. It is designed for board-to-board interconnect applications in electronic equipment requiring reliable connections under demanding conditions.

The housing is fabricated from high temperature thermoplastic material, suitable for reflow soldering processes and capable of operating in temperatures ranging from -65°C up to 130°C. The pins are made of phosphor bronze and plated similarly to provide low contact resistance and high durability.

This unshrouded header supports electrical currents up to 3 amps per contact and can withstand voltages up to 1500 volts, making it suitable for various industrial, electronic, and communication system uses. The precise pin dimensions include a 3.05 mm tail pin length for secure PCB solder termination and a 5.84 mm mating length for robust connector engagement. The connector system supports board-to-board connections and is intended for vertical mount orientation using through hole mounting technology.

Amphenol ICC offers this part with UL recognition under file number E66906, ensuring industry-standard compliance. The product is manufactured in France, guaranteeing quality and reliability.

This component is typically used in industrial automation, telecommunications equipment, measurement instruments, and other electronic assemblies where compact, high-performance PCB connectors are needed.

The pin header features phosphor bronze male contacts with phosphor bronze plating for enhanced conductivity. It is unshrouded to allow easy access for mating connectors. The thermoplastic housing supports high temperature operation, rated from -65°C to 130°C.

The product supports a maximum voltage of 1500 V and a current rating of 3 A per contact. The tail pin length is 3.05 mm and the mating pin length is 5.84 mm, optimized for secure solder termination. Designed as board-to-board connector with through hole mount type for reliable mechanical and electrical connection.

The pin pitch of 2.54 mm ensures compatibility with standardized PCB layouts. UL approval (E66906) certifies its conformance to recognized safety standards. Manufactured in France, ensuring high quality standards. Explore a wide range of PCB connectors and headers on EnvMart for diverse electronics and industrial applications.
