Omron Thermal Overload Relay 3 Pole Direct Mount 690V 15kW Power Rating Adjustable Current 10 to 14 A J7TKN
Specifications
| Country of Origin | India |
|---|---|
| Brand | Omron |
| Length | 126.5mm |
| Model | J7TKN |
| Depth | 70mm |
| Width | 45mm |
| Mount Type | Direct |
| Series | J7TKN |
| Power Rating | 15kW |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -25°C |
| Supply Voltage | 690V |
| Contact Voltage | 690V |
| Reset Method | Automatic |
| Relay Contact Current | 6A |
| Pole and Throw Configuration | 3 |
| FLC Motor Rating | 4, 6A |
| Adjustable Current Range | 10 → 14 A |
Key Features
- Designed for three-phase motors with a 3-pole direct mount configuration.
- Supports a supply voltage of 690V for high-voltage industrial installations.
- Provides protection for motors rated up to 15 kW power capacity.
- Features automatic reset method for seamless operation without manual intervention.
- Operates reliably in ambient temperatures ranging from -25°C to 60°C.
- Complies with IEC 60947-4-1, VDE 0660, and EN 60947-4-1 standards for safety and performance.
- Relay contact current rating is 6 A, suitable for downstream control circuit coordination.
Product Description
Omron J7TKN Thermal Overload Relay is a three-pole device designed to protect industrial three-phase motors by monitoring current and interrupting circuits upon detecting overload conditions. Featuring an adjustable current range of 10 to 14 A, it supports alternating current motor ratings of 4 A and 6 A full-load current (FLC), providing precise motor protection up to a power rating of 15 kW. This relay is intended for direct mounting in motor control panels and automation systems operating at supply voltages up to 690V.
Its automatic reset mechanism enables routine operations without manual resets, reducing downtime in industrial processes. The relay’s compact footprint (45mm width, 126.5mm length, 70mm depth) facilitates high-density panel installations, making it suitable for diverse applications including pumps, fans, and medium-power motors in manufacturing, HVAC, and automation sectors.
The operating temperature range from -25°C to 60°C allows use in various environmental conditions. This product complies with internationally recognized standards IEC 60947-4-1, VDE 0660, and EN 60947-4-1, ensuring interoperability and performance reliability in industrial electrical systems.
Adjustable current trip setting from 10 to 14 A for exact motor overload protection. Rated for a supply voltage of 690V suitable for high-voltage setups. Three-pole configuration ensures balanced phase monitoring. Power rating of 15 kW suitable for medium-sized motors.
Automatic reset function minimizes service interruptions. Compact dimensions aid installation in motor control panels. Wide environmental operating temperature range from -25°C to 60°C. Compliance with IEC 60947-4-1 and related standards for quality assurance.
This Omron thermal overload relay is ideal for industrial motor protection in manufacturing plants, water treatment facilities, HVAC systems, and agricultural machinery requiring reliable overload safeguarding. It provides effective coordination with contactors due to its 6 A auxiliary contact current rating, ensuring robust motor control solutions.
Explore additional options in Thermal Overload Relays and motor protection devices in the Electronics & Electricals category on EnvMart for comprehensive industrial automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power rating of this thermal overload relay is 15 kW, making it suitable for medium-sized motors.
It features an adjustable current range from 10 to 14 A, allowing for precise overload protection.
The relay supports a maximum supply voltage of 690V, suitable for high-voltage industrial applications.
This model has dimensions of 126.5mm in length, 45mm in width, and 70mm in depth.
It operates reliably in ambient temperatures ranging from -25°C to 60°C.
The automatic reset function allows the relay to reset itself after an overload condition without manual intervention, reducing downtime.
The relay contact current rating is 6 A, which is suitable for downstream control circuit coordination.
It complies with IEC 60947-4-1, VDE 0660, and EN 60947-4-1 standards for safety and performance.
This thermal overload relay is designed for direct mounting in motor control panels.
It is suitable for applications including pumps, fans, and medium-power motors in manufacturing, HVAC, and automation sectors.
The full-load current (FLC) motor ratings supported by this relay are 4 A and 6 A.
This model features a three-pole configuration, ensuring balanced phase monitoring for three-phase motors.
