Vishay Single Layer Ceramic Capacitor 4 nF 20kV DC Screw Terminal N4700 Dielectric ±20% Tolerance 715C20KTD40
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 20kV dc |
| Diameter | 60mm |
| Brand | Vishay |
| Height | 23mm |
| Model | 715C20KTD40 |
| Packaging | Bulk |
| Mount Type | Screw |
| Series | 715C |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±20 % |
| Capacitance | 4nF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Screw |
| Dissipation Factor | 0.2% |
| Standards/Approvals | RoHS |
| Package/Case | Disc |
| Pin Count | 2 |
| Dielectric | N4700 |
| Suppression Class | Class I |
Key Features
- Class 1 ceramic AC and DC disc capacitor with high voltage rating of 20,000 V DC.
- Capacitance of 4 nanofarads with ±20% tolerance.
- N4700 dielectric material ensuring reliable insulation and stability.
- Screw terminal type offering secure and easy mounting.
- Operating temperature range from -30°C to a maximum of 85°C.
- Disc package type with 60mm diameter and 23mm height dimensions.
- Dissipation factor of 0.2% at 1 kHz indicating low energy loss.
- RoHS compliant ensuring environmental safety.
Product Description
Vishay 715C20KTD40 is a high voltage class 1 single layer ceramic capacitor designed for demanding electronic applications requiring reliable high voltage handling. It features a capacitance of 4nF and is rated for 20kV DC.
The capacitor uses an N4700 dielectric providing excellent insulation properties and high voltage endurance. The screw terminal mount ensures robust mechanical connection, making installation and maintenance straightforward.
With a disc package measuring 60mm in diameter and 23mm in height, the capacitor suits various industrial and laboratory systems. It can operate within a temperature range of -30°C to 85°C, allowing use in environments with moderate thermal conditions.
The low dissipation factor of 0.2% at 1kHz means energy losses are minimal, enhancing circuit efficiency. Compliance with RoHS standards guarantees the product meets environmental safety regulations.
Class 1 ceramic AC and DC disc capacitor with high voltage rating of 20,000 V DC. Capacitance of 4 nanofarads with ±20% tolerance. N4700 dielectric ensuring stable performance. Screw terminal mounting for secure connections.
Operating temperature range from -30°C to 85°C. Disc form factor with 60mm diameter and 23mm height. Low dissipation factor of 0.2% at 1 kHz. RoHS compliant for environmental safety. Suitable for industrial, laboratory, welding, high voltage power supplies, CO2 laser, and X-ray equipment.
This capacitor is a suitable choice for engineers and designers working in industrial electronics, power supply design, medical equipment, and other high voltage applications. It balances electrical stability, mechanical reliability, and environmental adherence.
Explore more high quality electronic components and capacitors available at EnvMart for your industrial and technical projects.
Explore more products in our Single Layer Ceramic Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a maximum voltage of 20,000 V DC.
The capacitance value is 4 nanofarads with a tolerance of ±20%.
This capacitor features a screw terminal mount type for secure connections.
The capacitor has a diameter of 60mm and a height of 23mm.
It can operate in temperatures ranging from -30°C to a maximum of 85°C.
It uses N4700 dielectric material, which provides reliable insulation and stability.
The dissipation factor is 0.2% at 1 kHz, indicating low energy loss.
Yes, it is RoHS compliant, ensuring it meets environmental safety standards.
It is suitable for use in industrial electronics, power supply design, medical equipment, and high voltage applications.
This model has a pin count of 2.
The capacitor is manufactured in Germany.
It belongs to the 715C series.
