Amphenol Communications Solutions EconoStik Series Vertical Surface Pin Header 6 Contacts 2.54mm Pitch 1 10129380-906002ALF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1500V |
| Brand | Amphenol Communications Solutions |
| Orientation | Vertical |
| Current | 3A |
| Model | 10129380-906002ALF |
| Mount Type | Surface |
| Housing Material | Thermoplastic |
| Contact Material | Brass |
| Series | EconoStik |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Mating Pin Length | 8.08mm |
Key Features
- Compatible with board-to-board connector systems.
- Housing made of high-temperature thermoplastic ensuring durability.
- Contacts made of brass with 1μin gold plating for reliable connectivity.
- Operates safely between -55°C to 105°C temperature range.
- Designed to handle up to 3A current and voltage rating of 1500V.
- Unshrouded pin header with male contacts and vertical orientation.
- Mating pin length of 8.08 mm providing secure connections.
- RoHS compliant and lead-free, meeting environmental standards.
Product Description
Amphenol Communications Solutions 10129380-906002ALF EconoStik Series Vertical Surface Pin Header is designed with 6 brass contact pins plated with 1μin gold for high reliability and low contact resistance. The housing is constructed from a high-temp thermoplastic material allowing operation in harsh industrial environments from -55°C to 105°C. This 1-row, 2.54 mm pitch pin header is surface mount capable and unshrouded, providing easy integration into PCB layouts.
The pin header supports up to 3A current and withstands voltages up to 1500V, ensuring safe and efficient signal transmission. Its vertical orientation and 8.08 mm mating pin length make it ideal for board-to-board connections in compact electronics. Applications include industrial control systems, test equipment, metering devices, point-of-sale machines, set-top boxes, surveillance equipment, and vending machines.
The product's customized mating and tail lengths plus optional custom polarization allow flexibility for various circuit designs. It is tested for up to 50 mating cycles to guarantee long-term durability.
Compatible with board-to-board connector systems. High-temperature thermoplastic housing for durability. Brass contacts with 1μin gold plating for optimal conductivity. Operating temperature range from -55°C to 105°C. Current rating of 3A and voltage rating of 1500V.
Unshrouded vertical orientation with 6 male contacts. Surface mount termination type. Mating pin length is 8.08 mm ensuring secure connections. RoHS compliant and lead-free. Ideal for industrial, metering, POS, set-top box, and surveillance applications.
Explore more PCB Pin Headers and connectors at EnvMart for quality industrial electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 3A.
It has a voltage rating of 1500V.
The pin header operates safely between -55°C to 105°C.
This model features 6 contacts.
The pitch size is 2.54mm.
The contacts are made of brass and are plated with 1μin gold.
It utilizes surface mount termination.
The mating pin length is 8.08 mm.
This model has a vertical orientation.
Yes, it is RoHS compliant and lead-free, meeting environmental standards.
It is suitable for applications including industrial control systems, test equipment, metering devices, and point-of-sale machines.
The country of origin for this product is India.
