Schurter 250V AC 10A Screw IEC Connector 2 Pole Quick Connect 3-105-326

Free Delivery in India | Lowest Global Shipping Charges

Schurter 250V AC 10A Screw IEC Connector 2 Pole Quick Connect 3-105-326

Name: Schurter 250V AC 10A Screw IEC Connector 2 Pole Quick Connect 3-105-326
Brand: Schurter
SKU: 158602



Category IEC Connector Brand Schurter Condition New

Specifications

Country of Origin	India
Voltage	250V ac
Brand	Schurter
Current	10A
Height	47mm
Filter Type	Line
Depth	65.9mm
Mount Type	Screw
Operating Frequency	50, 60Hz
Switch Type	2 Pole
Series	DD14
Termination Type	Quick Connect
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-25°C
Panel Mount	Snap-in or screw-on mounting from front side
Fuse Size	5 x 20 mm
IEC Connector Type	C14
4 Functions	Appliance Inlet Protection class I, Line Switch 2-pole, Fuseholder for fuse-links 5 x 20 mm 1 or 2 pole, 2-Stages line filter in standard and medical version

Key Features

Features a 2 Pole line switch with a 2-stages line filter for enhanced power quality.
Fitted with fuseholder supporting 5 x 20 mm fuse links.
Mounting options include snap-in or screw-on for panel installation.
Quick connect terminals sized 6.3 x 0.8 mm for secure and easy wiring.
Designed with an aluminium case providing excellent shielding and durability.
Operates reliably within temperature range from -25°C to 85°C.
Compact and flat design ideal for low profile applications.
Suitable for use in various industrial and medical electronic equipment.

Product Description

Schurter 3-105-326 IEC Connector is a high-quality power entry module designed for use in industrial, medical, and commercial electronic applications. It operates at 250V AC and 10A current rating, featuring a screw mounting type and quick connect termination for ease of installation.

This ultra-compact connector incorporates a 2 Pole line switch combined with a 2-stages line filter to enhance power quality and protect connected equipment. The fuseholder accommodates 5 x 20 mm fuse links, available as one or two-pole options, facilitating flexible circuit protection within a single component. The connector features V-Lock cord retaining and a versatile panel mount design allowing snap-in or screw-on installation from the front side.

Its aluminium casing offers superior shielding against electromagnetic interference, suitable for environments sensitive to electrical noise. The operating temperature range from -25°C to 85°C ensures reliable performance under various conditions. Quick connect terminals sized 6.3 x 0.8 mm allow straightforward, secure electrical connections.

The SCHURTER 3-105-326 is ideal for applications requiring a compact, robust, and versatile IEC C14 appliance inlet with additional filter and switch functions. Its flat design suits low-profile electronic assemblies where space constraints are critical.

Includes 2-pole line switch and fuseholder for 5 x 20 mm fuses. Panel mount with snap-in or screw-on installation options. Two-stage line filter for improved power quality. Quick connect terminals enable easy wiring. Aluminium case provides effective electromagnetic shielding.

Compact size with height 47 mm and depth 65.9 mm. Wide temperature operating range from -25°C to 85°C. Compliant with industrial and medical equipment requirements.

This connector type is commonly used in electronic manufacturing, laboratory devices, HVAC systems, and other industrial equipment requiring reliable power connections with integrated filtering and switching features.
