KEMET SPST Through Hole Reed Switch 300 mA 110 V AC/DC OHD1-115M

The KEMET OHD1-115M SPST Through Hole Reed Switch is engineered for dependable switching in diverse industrial, electronic, and automation sectors. It supports a contact configuration of SPST with a maximum switching current of 300 mA and voltage rating of 110 V AC/DC, making it suitable for precise control of low to medium power signals.

This reed switch incorporates a nickel-iron alloy contact material to ensure longevity and minimal contact resistance of 150 milliohms. Its wire terminal and through-hole mount design facilitate easy integration into printed circuit boards and other assemblies.

With a compact size of 18 mm length, 5.5 mm width, and 5.6 mm depth, the component fits seamlessly into various compact devices. The operating temperature range from -20°C to 150°C allows reliable use in harsh environments including industrial automation, HVAC systems, and electronic instrumentation.

The OHD series features high-speed response and extended operational life with excellent resistance to environmental factors such as dust, corrosion, and explosions. Typical applications include temperature detection, overheating monitoring in power transistors, power modules, motors, amplifiers, hard disk drives, and other general electrical appliances.

Contact configuration is Single Pole Single Throw (SPST) for precise switching. Maximum switching current rating of 300 mA supports reliable circuit operations. Maximum switching power capacity of 6 W allows diverse application usage.

Maximum switching voltage of 110 V AC/DC suits electronic control systems. Low contact resistance of 150 milliohms minimizes energy loss. Durable nickel iron alloy contact material ensures long-lasting performance. Through hole mount type with wire terminals enables secure and easy PCB mounting.

Wide operating temperature range from -20°C to 150°C for environmental durability. Compact and lightweight with dimensions 18 mm x 5.5 mm x 5.6 mm. High-speed response and long operational life increase reliability. Manufactured in Japan guaranteeing superior quality standards.

This reed switch from KEMET is ideal for industrial, laboratory, and electronic automation applications where precise and reliable switching is critical. It is well-suited for integration in systems for temperature sensing, overheating protection, and electrical appliance control.
