KEMET SPST Through Hole Reed Switch 300 mA 110 V AC/DC OHD1-105M
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | KEMET |
| Length | 18mm |
| Model | OHD1-105M |
| Depth | 5.6mm |
| Width | 5.5mm |
| Mount Type | Through Hole |
| Contact Material | Nickel Iron Alloy |
| Series | OHD1 |
| Maximum Switching Current | 300mA |
| Maximum Operating Temperature | 150°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -20°C |
| Terminal type | Wire |
| Contact Resistance | 150mΩ |
| Maximum Switching Power | 6W |
| Maximum Switching Voltage | 110V ac/dc |
Key Features
- The switch features a SPST contact configuration ensuring reliable single-pole single-throw operation.
- Maximum switching power capacity is rated at 6 W for versatile applications.
- Contact resistance is low at 150 milliohms, using a Nickel Iron Alloy contact material for durability.
- Constructed with wire terminals and through-hole mounting for ease of PCB integration.
- Compact dimensions with length 18 mm, width 5.5 mm, and depth 5.6 mm enable space-efficient installation.
- Operational temperature range extends from -20°C up to 150°C for wide environmental tolerance.
- Japan origin ensures high manufacturing quality and reliability.
- Ideal for atmospheric temperature detection, overheating monitoring, and switching in power modules, room heaters, motors, and general electronic appliances.
Product Description
KEMET OHD1-105M SPST Through Hole Reed Switch is engineered for robust switching of electrical signals with maximum switching current of 300 mA and a maximum switching voltage of 110 V AC/DC. This reed switch offers high reliability for on/off operations with a maximum switching power rating of 6 W.
The contacts are made from Nickel Iron Alloy, providing low contact resistance of 150 milliohms, facilitating fast and consistent electrical conduction. The terminal type consists of wires, and the mounting style is through-hole, making it ideal for secure PCB installation.
This compact switch comes with dimensions of 18 mm length, 5.5 mm width, and 5.6 mm depth, suited for applications requiring small form factor components. It can withstand operating temperatures between -20°C and 150°C, suitable for demanding environmental conditions.
The OHD1 series incorporates advanced design concepts for thermal problem countermeasures, providing excellent environmental durability, corrosion resistance, and long operational life. It is compatible with signals ranging from very low power (0.1 mW or less) to 6 W high power levels, supporting extremely simple circuit designs.
Typical industrial and commercial applications include temperature sensing and overheating detection in power transistors, power modules, room heaters, amplifiers, motors, hard disk drives, floppy disk drives, and other electronic devices requiring reliable switching mechanisms.
The switch offers a SPST contact configuration for single-pole single-throw switching. Maximum current handling capability is 300 mA with a power rating of 6 W. Low contact resistance of 150 mΩ ensures minimal signal loss.
Durable Nickel Iron Alloy contacts support longevity and environmental resistance. Compact through-hole wire terminal design facilitates PCB assembly. Wide temperature operation range from -20°C to 150°C suits industrial environments.
Developed with thermal guard features to combat thermal issues. Manufactured in Japan guaranteeing premium build quality. Explore more electronic switch solutions in the Reed Switch category at EnvMart for reliable and high-performance industrial electrical components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current for the KEMET OHD1-105M reed switch is 300 mA.
This model has a maximum switching voltage of 110 V AC/DC.
The contact configuration of this switch is SPST (Single-Pole Single-Throw).
The dimensions of this reed switch are 18 mm in length, 5.5 mm in width, and 5.6 mm in depth.
The contact resistance of the KEMET OHD1-105M is 150 milliohms.
The operational temperature range for this model extends from -20°C to 150°C.
This reed switch utilizes a through-hole mounting style, making it suitable for PCB integration.
The contacts are made from Nickel Iron Alloy, which provides durability and low contact resistance.
The maximum switching power rating for the KEMET OHD1-105M is 6 W.
The KEMET OHD1-105M features wire terminals for connection.
This reed switch is suitable for applications such as temperature sensing, overheating detection, and switching in various electronic devices.
This model is manufactured in Japan, ensuring high build quality.
