Vishay Single Layer Ceramic Capacitor 1 nF 27kV dc ±20 % N4700 Dielectric Screw Mount 85 °C Max Op. Temp. 715C40KTD10

Free Delivery in India | Lowest Global Shipping Charges

Vishay Single Layer Ceramic Capacitor 1 nF 27kV dc ±20 % N4700 Dielectric Screw Mount 85 °C Max Op. Temp. 715C40KTD10

Name: Vishay Single Layer Ceramic Capacitor 1 nF 27kV dc ±20 % N4700 Dielectric Screw Mount 85 °C Max Op. Temp. 715C40KTD10
Brand: Vishay
SKU: 156837
Price: 20.22 USD
Availability: InStock



Category Single Layer Ceramic Capacitors Brand Vishay Condition New

Specifications

Country of Origin	Germany
Voltage	27kV dc
Diameter	44mm
Brand	Vishay
Height	31mm
Model	715C40KTD10
Packaging	Bulk
Mount Type	Screw
Series	715C40KT
Maximum Operating Temperature	85°C
Tolerance	±20 %
Capacitance	1nF
Minimum Operating Temperature	-30°C
Terminal type	Screw
Dissipation Factor	0.2%
Standards/Approvals	RoHS
Package/Case	Moulded Epoxy
Dielectric	N4700
Suppression Class	Class I

Key Features

Equipped with N4700 strontium-based class 1 ceramic dielectric for stability.
Screw terminal mount type for secure and reliable installation.
Maximum operating temperature of 85 °C ensuring robust performance.
Low dissipation factor of 0.2% at 1 kHz for minimal energy loss.
Constructed with moulded epoxy package and bulk packaging option.
Compatible for high voltage AC and DC power supplies and laser equipment.
Designed for industrial and laboratory use with RoHS compliance.
Manufactured in Germany with stringent quality controls.

Product Description

Vishay 715C40KTD10 single layer ceramic capacitor is engineered to support high voltage applications up to 27kV DC with a capacitance of 1 nF and a tolerance of ±20 %. This capacitor uses the N4700 dielectric, a strontium-based class 1 ceramic material known for excellent electrical stability and negligible piezoelectric effects improving accuracy and reducing noise in circuits.

Featuring a screw terminal mount type, it enables solid mechanical and electrical connection suitable for demanding industrial environments. The capacitor's moulded epoxy case offers mechanical protection and electrical insulation, with bulk packaging providing convenience for volume applications.

This component operates reliably between -30°C and 85°C, suitable for high voltage power supplies, CO2 lasers, X-ray equipment, and similar industrial and laboratory instrumentation. Its low dissipation factor of 0.2% at 1 kHz minimizes power losses and thermal buildup, enhancing efficiency.

Dimensionally, it measures 31 mm in height and 44 mm in diameter, supporting integration into compact assemblies. The product complies with RoHS standards, ensuring environmental and safety compliance.

Manufactured in Germany, this capacitor adheres to strict quality standards for durability and performance. It is ideal for electrical engineers and technicians focusing on precision high voltage capacitor applications in industrial, medical, and research domains.

Equipped with N4700 strontium-based ceramic dielectric. Screw terminal mount for secure installation. High voltage rating of 27kV dc supporting demanding uses. Low dissipation factor reduces energy loss. RoHS compliant and environmentally safe.

Compact size of 31 mm height by 44 mm diameter. Operates reliably up to 85 °C maximum temperature. Bulk packaging optimal for production runs and inventory. Produced in Germany under stringent quality controls. Explore our broad range of industry-grade capacitors and electronic components at EnvMart for professional and industrial requirements.
