Eaton Monitoring Relay 180/280 V AC Monitor Range CO Contact DIN Rail Mount 4A 184769 EMR6-AWN280-K-1

Free Delivery in India | Lowest Global Shipping Charges

Eaton Monitoring Relay 180/280 V AC Monitor Range CO Contact DIN Rail Mount 4A 184769 EMR6-AWN280-K-1

Name: Eaton Monitoring Relay 180/280 V AC Monitor Range CO Contact DIN Rail Mount 4A 184769 EMR6-AWN280-K-1
Brand: Eaton
SKU: 154056
Price: 407.23 USD
Availability: InStock



Category Monitoring Relays Brand Eaton Condition New

Specifications

Country of Origin	Germany
Brand	Eaton
Height	78mm
Length	109.5mm
Model	184769 EMR6-AWN280-K-1
IP Rating	IP20, IP50
Width	22.5mm
Mount Type	DIN Rail
Series	EMR6
Maximum Operating Temperature	60°C
Contact Configuration	CO
Minimum Operating Temperature	+60°C
Terminal type	Screw
Standards/Approvals	UL, IEC 60068-2-30, RoHS, CCC, IEC, GL, CSA
Contact Current	4A
Supply AC Voltage	180, 280V ac
Monitoring Voltage Range	180/280 V ac

Key Features

Designed for DIN rail mounting with screw terminals for secure installation.
Operates within a voltage supply of 180 to 280 V AC with a contact current rating of 4A.
Built to withstand ambient temperatures from -25°C to 60°C, ensuring durability.
Offers IP20 and IP50 ratings for protection of terminals and enclosure.
Equipped with LED status indicators for easy monitoring of device status.
Mechanical lifespan rated for 30 million cycles for long service life.
Complies with UL, IEC 60068-2-30, RoHS, CCC, GL, and CSA standards.
Suitable for monitoring phase sequence, imbalance, failure, undervoltage, and overvoltage.

Product Description

Eaton 184769 EMR6-AWN280-K-1 monitoring relay provides comprehensive protection for electrical switchgear by continuously monitoring three-phase power supplies within a 180 to 280 V AC range. It features a CO contact configuration and is designed for DIN rail mounting, facilitating easy installation in industrial and commercial setups.

This relay is engineered to detect critical power supply anomalies including phase sequence errors, phase imbalance, phase failure, undervoltage, and overvoltage conditions, helping to prevent damage to connected equipment and reducing downtime.

Constructed to handle a contact current of 4A, the relay operates reliably within ambient temperatures ranging from -25°C up to 60°C. Its robust housing provides an IP20 rating for terminals and IP50 for the enclosure, enabling protection against dust and mechanical impacts.

The device features LED status indicators to enhance user interface and operational monitoring. It has an exceptional mechanical lifespan rated for 30 million operations, reflecting its high durability and efficiency. Compliance with international standards such as UL, IEC 60068-2-30, RoHS, CCC, GL, and CSA confirms its quality and safety credentials.

Applications span electric engineering, factory automation, light industrial environments, low-voltage switch technology, monitoring equipment, process control engineering, and residential facilities. This versatile relay is a cost-effective solution to enhance power supply reliability and protect critical infrastructure.

Designed for DIN rail mounting and utilizes screw terminals for secure connectivity. Offers high shock resistance and burst/surge protection ensuring operational stability. LED indicators facilitate easy status monitoring and diagnostics.

Wide ambient temperature range from -25°C to 60°C supports various environments. Robust mechanical lifespan of 30 million cycles ensures longevity and reliability. Maintains IP20 and IP50 protection ratings for terminals and enclosure respectively.

Certified under UL, IEC, RoHS, CCC, GL, and CSA standards guaranteeing compliance and safety. Explore the complete range of Eaton Monitoring Relays at EnvMart for dependable power management and industrial automation systems integration.
