JST SUR Series Right Angle Shrouded PCB Header 8 Contacts 0.8 mm Pitch 1 Row SM08B-SURS-TF (LF)(SN)

Free Delivery in India | Lowest Global Shipping Charges

JST SUR Series Right Angle Shrouded PCB Header 8 Contacts 0.8 mm Pitch 1 Row SM08B-SURS-TF (LF)(SN)



Category PCB Headers Brand JST Condition New

Specifications

Country of Origin	Malaysia
Voltage	30V
Brand	JST
Orientation	Right Angle
Current	200mA
Model	SM08B-SURS-TF (LF)(SN)
Mount Type	PCB
Housing Material	Polyamide
Contact Material	Copper Alloy
Series	SUR
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-25°C
Number of Rows	1
Pitch	0.8mm
Contact Plating	Copper
Number of Contacts	8
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	0.45mm

Key Features

The header uses polyamide housing providing durability and electrical insulation.
Rated for a maximum current of 200mA and voltage of 30V, suitable for low power electronic applications.
Shrouded design ensures reliable connection and protection against accidental contact.
Contact material is copper alloy with copper plating, finished for optimal conductivity and corrosion resistance.
Tail pins are designed for solder termination with a length of 0.45 mm for secure mounting on PCBs.
Operates reliably within a temperature range of -25°C to 85°C.
Connector system is wire-to-board type, designed for easy PCB mounting with right angle orientation.
Compact design reduces board occupation space compared to conventional 1.0 mm pitch connectors.

Product Description

The JST SM08B-SURS-TF (LF)(SN) is a premium right angle shrouded PCB header from JST's SUR series, engineered for high-density and compact electronic applications. Featuring 8 contacts arranged in a single row with a fine 0.8 mm pitch, this component ensures precise and reliable wire-to-board connections for modern PCB assemblies.

Constructed with a polyamide housing, the header offers excellent insulation and durability, suitable for demanding industrial and electronic environments. Its shrouded design enhances safety by preventing accidental contact and improving connector retention.

The contacts are crafted from copper alloy and plated with copper to provide superior electrical conductivity and resistance to corrosion, ensuring long-term performance. Tail pins measure 0.45 mm in length and use solder termination type for dependable PCB mountability. The right angle orientation design optimizes board layout by minimizing the connector’s footprint compared to traditional 1.0 mm pitch headers, reducing the overall space by approximately 34%.

Operational temperature range is from -25°C up to 85°C, making it suitable for various electronics in industrial, manufacturing, and commercial sectors. The design includes a twin U-slot insulation displacement mechanism to accommodate super fine wires, improving connection reliability and ease of assembly.

The header is designed for wire-to-board connector applications and mounts directly to PCBs. Supports currents up to 200mA and voltage up to 30V, ideal for signaling and low power circuits. Polyamide housing material provides excellent mechanical integrity and chemical resistance.

Shrouded structure offers enhanced contact protection and secure mating. Copper alloy contacts with copper plating ensure stable electrical contact with low resistance. Tail pin length of 0.45 mm optimizes the solder joint reliability.

Compact footprint minimizes PCB space usage, increasing design flexibility. Manufactured in Malaysia following JST’s strict quality control standards.

This JST SUR Series right angle shrouded PCB header is well-suited for industrial automation, electronic manufacturing, communication devices, and instrumentation applications. EnvMart offers this reliable connector as part of its comprehensive range of PCB connectors, facilitating efficient and robust electronic assemblies.

Explore more products in our PCB Headers category.
