KEMET R82 Film Capacitor 22 nF ±10% 400 V DC 200 V AC Through Hole Radial Lead R82MC2220Z350K

KEMET R82MC2220Z350K Film Capacitor is a high-quality, through-hole radial lead capacitor featuring a metallized polyester film construction and ±10% capacitance tolerance of 22 nF. Designed for industrial and automotive electronic applications, it supports coupling, bypassing, blocking, timing, and decoupling functions in circuits.

This capacitor is rated for a maximum DC voltage of 400 V and AC voltage of 200 V, making it suitable for various power and signal processing applications. It offers reliable performance across a wide operating temperature range from -55°C to 105°C, ensuring durability under extreme environmental conditions.

The radial leads are tin-plated wire type with 5 mm pitch and 17 mm lead length to facilitate secure and stable mounting on printed circuit boards (PCBs). The product is fully compliant with RoHS directives and IEC 60384-2 standards, and meets automotive quality requirements under the AEC-Q200 standard, making it apt for automotive electronics design and manufacturing.

This capacitor features a compact form factor with dimensions of 9.5 mm height, 7.2 mm length, and 4.5 mm width, along with a lead diameter of 0.5 mm. It is supplied in bags, suitable for batch assembly operations. Its metallized polyester film and self-healing properties enhance longevity and operational reliability in demanding electrical environments.

Constructed with metallized polyester film and radial tin-plated wire leads for stability. Rated DC voltage of 400 V and AC voltage of 200 V. Operating temperature from -55°C to 105°C ensures broad environmental range capability.

Complies with RoHS, IEC 60384-2 standards and automotive AEC-Q200 certification. Radial lead pitch of 5 mm and lead length of 17 mm for precise PCB mounting. Compact size with dimensions 9.5 mm × 7.2 mm × 4.5 mm and 0.5 mm lead diameter.

Applications include coupling, bypassing, blocking, timing, and decoupling circuits. Self-healing design improves capacitor longevity and reliability. Package includes capacitors in bags suitable for assembly lines.

This film capacitor is widely used in industrial electronics, automotive electronics, manufacturing, power supply filtering, and other commercial electrical applications. Its robustness and compliance standards make it an essential component for engineers and designers requiring dependable capacitive solutions.
