Microchip PIC16F18854-I/SP 16-Bit PIC Microcontroller 32 MHz, 7kB FLASH, 28-Pin SPDIP
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 5.08mm |
| Length | 35.56mm |
| Model | PIC16F18854-I/SP |
| Width | 7.37mm |
| Mount Type | Surface |
| Series | PIC16F |
| Maximum Operating Temperature | 85°C |
| Package Type | SPDIP |
| Minimum Operating Temperature | -40°C |
| Ram size | 512kB |
| Interface Type | FSR/INDF, NVMREG |
| Standards/Approvals | RoHS |
| Pin Count | 28 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 1.8V |
| Device Core | PIC |
| Program Memory Size | 7kB |
| Maximum Clock Frequency | 32MHz |
| Number of Programmable I/Os | 25 |
| Analogue Comparators | 2 |
| Number of Timers | 2 |
| Instruction Set Architecture | RISC |
| ADCs | 24 x 10 Bit |
| Program Memory Type | FLASH |
| DACs | 1 x 5 Bit |
Key Features
- Operates at a maximum clock frequency of 32 MHz for fast processing.
- Equipped with 7kB of FLASH program memory and 512 bytes of RAM for efficient storage.
- Supports 25 programmable I/Os and includes 24 10-bit ADC channels for analog sensing.
- Operates over a wide voltage range from 1.8V to 5.5V for flexible power requirements.
- Features two timers, one 5-bit DAC, and two analog comparators for advanced control functions.
- Designed with Enhanced Mid-range RISC core and 49 instruction set with 16 stack levels.
- RoHS compliant and built to support automotive grade temperature range from -40°C to 85°C.
- The compact SPDIP 28-pin form factor measures 35.56 mm length, 7.37 mm width, and 5.08 mm height.
Product Description
Microchip PIC16F18854-I/SP is a 16-bit PIC microcontroller designed for embedded system solutions requiring low power and efficient peripheral integration. It operates at a maximum clock rate of 32 MHz and provides 7kB of FLASH program memory complemented by 512 bytes of RAM to handle demanding applications.
This microcontroller supports 25 programmable input/output pins, enabling versatile interface options with sensors and actuators. It is equipped with 24 channels of 10-bit ADC for high-resolution analog signal acquisition.
The device includes two timers, one digital-to-analog converter (DAC) with 5-bit resolution, and two analog comparators, facilitating sophisticated control and monitoring capabilities. The architecture is based on an enhanced mid-range RISC core featuring 49 instructions and a 16-level stack, ensuring efficient program execution.
Power management is flexible with an operating voltage range from 1.8V minimum to 5.5V maximum. The operating temperature scope ranges from -40°C to 85°C, making it suitable for automotive and industrial environments. It complies with RoHS standards, affirming its environmental safety.
The package type is SPDIP with 28 pins, compactly sized at 35.56 mm length, 7.37 mm width, and 5.08 mm height, suitable for various PCB designs. Operates at 32 MHz maximum clock frequency. 7kB FLASH memory and 512 bytes RAM provide storage resources.
Supports 25 programmable I/O pins for flexible interfacing. Includes 24 10-bit ADC channels for precise analog inputs. Features 5-bit DAC, two analog comparators, and two timers. Enhanced Mid-range RISC core with 49 instructions and 16 stack levels.
Wide operating voltage range from 1.8V to 5.5V. Operating temperature range from -40°C to 85°C suitable for automotive. Compliant with RoHS environmental standards. Compact 28-pin SPDIP package measuring 35.56 x 7.37 x 5.08 mm.
This microcontroller is ideal for industrial, automotive, HVAC controls, and general embedded applications requiring efficient power management and robust peripheral support. Browse more Microchip Microcontrollers and related electronic components on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Microchip PIC16F18854-I/SP operates at a maximum clock frequency of 32 MHz, allowing for fast processing capabilities.
This model is equipped with 7kB of FLASH program memory, providing ample storage for applications.
It operates over a wide voltage range from 1.8V to 5.5V, offering flexibility in power requirements.
This microcontroller supports 25 programmable I/O pins, allowing for versatile interfacing options.
It includes 24 channels of 10-bit ADC, enabling high-resolution analog signal acquisition.
The PIC16F18854-I/SP comes in a 28-pin SPDIP package, making it suitable for various PCB designs.
It operates within a temperature range from -40°C to 85°C, suitable for automotive and industrial applications.
This model features an Enhanced Mid-range RISC core with 49 instructions and a 16-level stack for efficient program execution.
Yes, it is RoHS compliant, ensuring it meets environmental safety standards.
It includes two timers, one 5-bit DAC, and two analog comparators for advanced control functions.
The dimensions of this model are 35.56 mm in length, 7.37 mm in width, and 5.08 mm in height.
It is designed for industrial, automotive, HVAC controls, and general embedded applications requiring efficient power management and robust peripheral support.
