SMC Pneumatic Solenoid/Pilot-Operated Control Valve 3/3 Solenoid M5 x 0.8 24V DC VQC4000

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Solenoid/Pilot-Operated Control Valve 3/3 Solenoid M5 x 0.8 24V DC VQC4000



Category Pneumatic Solenoid Valves Brand SMC Condition New

Specifications

Country of Origin	Japan
Voltage	24V dc
Brand	SMC
Body Material	Die Cast Zinc
Maximum Operating Pressure	0.7 Mpa
Height	163mm
Length	209mm
Model	VQC4000
Enclosure	dust proof (conforms to IP67)
Operating Pressure	1.0MPa [0.7MPa (low wattage)]
Width	101.2mm
Mount Type	Base
Series	VQC4000
Number Of Ports	5
Maximum Operating Temperature	50°C
Port Type	Support, PE, EXH, Cylinder
Number of Positions	3
Port Size	M5 x 0.8
Seal Material	Rubber
Minimum Operating Temperature	-10°C
Actuation Type	Solenoid
Fluid	air/inert gas
Standards/Approvals	RoHS
Connection Thread Standard	M5 x 0.8
Minimum Pilot Pressure	0.15MPa
Valve Function	3/3
Solenoid Type	Single
Port Gender	Female
Solenoid Power Consumption	0.4W
Effective area (Cv)	1.7 metal seal, 2.0 rubber seal

Key Features

Operates at a voltage of 24V DC with low power consumption of 0.4W.
Constructed with die cast zinc body for durability.
Features 3/3 valve function with 3 positions and 5 ports.
Suitable for air and inert gases with a maximum operating pressure of 0.7 MPa.
Comfortably operates between temperatures of -10°C and 50°C.
Includes rubber seals ensuring reliable sealing performance.
Designed for base mounting with female ports sized M5 x 0.8.
Compliance with RoHS standards and dust-proof enclosure meeting IP67.

Product Description

SMC VQC4000 Pneumatic Solenoid/Pilot-Operated Control Valve is a robust 3/3 solenoid valve designed for precise pneumatic control in industrial environments. Operating at 24V DC with a low 0.4W solenoid power, it efficiently controls airflow for automation and pneumatic systems.

The valve features a die cast zinc body for enhanced mechanical strength and durability under tough operational conditions. Its base mount design with female M5 x 0.8 ports supports easy integration into manifold blocks and systems.

With 5 ports and 3 positions, this valve provides flexible control pathways, suitable for air and inert gases with a maximum operating pressure of 0.7 MPa. The valve operates reliably within a temperature range of -10°C to 50°C, accommodating various industrial temperatures.

Equipped with rubber seals and conforming to RoHS standards, the valve ensures a tight seal and environmental compliance. Its dust-proof enclosure rated to IP67 protects the internal components against dust and moisture, extending operational lifespan.

Physical dimensions are 209mm in length, 163mm in height, and 101.2mm in width, making it a compact solution for pneumatic control. The valve’s effective flow areas (Cv) are 1.7 for metal seals and 2.0 for rubber seals, optimizing performance for different sealing needs.

This pilot-operated valve includes features like a maximum pilot pressure of 0.7 MPa and minimum pilot pressure of 0.15 MPa, enhancing control accuracy and responsiveness in pneumatic circuits.

Operates with air/inert gases at up to 1.0 MPa pressure. Designed for industrial and manufacturing pneumatic applications. Compatible with manifolds using multi-pin connectors for flexible wiring setups. Conforms to IP67 dust-proof enclosure standards ensuring protection in harsh industrial environments.

Manufactured in Japan, the valve represents high-quality pneumatic engineering with long service life and outstanding response time. Perfect for use in automation, manufacturing, HVAC, and other industrial sectors requiring reliable pneumatic valve control.
