RS PRO Pluggable Terminal Block 4-Contact, 5 mm Pitch, 1 Row, 450V, 15A Current, Polyamide 66 Housing 144-4051

Free Delivery in India | Lowest Global Shipping Charges

RS PRO Pluggable Terminal Block 4-Contact, 5 mm Pitch, 1 Row, 450V, 15A Current, Polyamide 66 Housing 144-4051

Name: RS PRO Pluggable Terminal Block 4-Contact, 5 mm Pitch, 1 Row, 450V, 15A Current, Polyamide 66 Housing 144-4051
Brand: RS PRO
SKU: 146611



Category Pluggable Terminal Blocks Brand RS PRO Condition New

Specifications

Country of Origin	India
Voltage	450V
Brand	RS PRO
Colour	Green
Orientation	Straight
Current	15A
Length	20mm
Model	144-4051
Depth	18.1mm
Width	15.05mm
Housing Material	Polyamide 66
Number of Rows	1
Pitch	5mm
Number of Contacts	4
Minimum Wire Size mm²	0.32mm²
Maximum Wire Size mm²	1.6mm²
Minimum Wire Size AWG	28AWG
Maximum Wire Size AWG	14AWG
Wire Connection Method	Screw

Key Features

This terminal block supports a current rating of 15 amperes.
Designed with a 5 mm pitch to accommodate wiring spacing efficiently.
Constructed with durable Polyamide 66 housing for electrical insulation and flame resistance.
Equipped with screw wire connection method for secure and reliable contacts.
Suitable for wires ranging from 0.32 mm² (28AWG) to 1.6 mm² (14AWG).
Compact dimensions with length 20 mm, width 15.05 mm, and depth 18.1 mm.
Available in green color with straight orientation for easy installation.
Meets UL94-V0 flame retardant standards through housing material specification.

Product Description

RS PRO 144-4051 Pluggable Terminal Block is a 4-contact, 1-row connector featuring a 5 mm pitch and rated for 15 amperes at 450 volts. Manufactured with a green-colored Polyamide 66 housing, it offers excellent electrical insulation and UL94-V0 flame retardant properties suitable for various industrial and electronic applications.

The terminal block supports wire sizes from 0.32 mm² (28AWG) to 1.6 mm² (14AWG) and utilizes a professional screw connection system to ensure secure and stable wire contacts. Its compact dimensions of 20 mm length, 15.05 mm width, and 18.1 mm depth allow it to fit neatly in control panels and electronic assemblies.

This pluggable terminal block includes practical features such as captive screws and guided pin alignment, enhancing assembly precision and reducing installation errors. The straight orientation design supports versatile mounting configurations.

Due to its robust polyamide housing and reliable screw clamp terminals, the 144-4051 terminal block is ideal for industrial automation systems, control cabinets, electronic equipment, and manufacturing setups requiring dependable electrical connections.

This terminal block supports a current rating of 15 amperes. Designed with a 5 mm pitch to accommodate wiring spacing efficiently. Constructed with durable Polyamide 66 housing for electrical insulation and flame resistance.

Equipped with screw wire connection method for secure and reliable contacts. Suitable for wires ranging from 0.32 mm² (28AWG) to 1.6 mm² (14AWG). Compact dimensions with length 20 mm, width 15.05 mm, and depth 18.1 mm. Available in green color with straight orientation for easy installation.

Meets UL94-V0 flame retardant standards through housing material specification. Explore the Electronics Components section in EnvMart for high-quality RS PRO terminal blocks and connectors optimized for electronic, industrial, and manufacturing applications.
