HARWIN Datamate L-Tek Series PCB Header, Straight, Through Hole, 3 Contacts, 2 mm Pitch, 1 Row, Shrouded, Gold M80-8820342

Free Delivery in India | Lowest Global Shipping Charges

HARWIN Datamate L-Tek Series PCB Header, Straight, Through Hole, 3 Contacts, 2 mm Pitch, 1 Row, Shrouded, Gold M80-8820342

Name: HARWIN Datamate L-Tek Series PCB Header, Straight, Through Hole, 3 Contacts, 2 mm Pitch, 1 Row, Shrouded, Gold M80-8820342
Brand: HARWIN
SKU: 88035
Price: 20.22 USD
Availability: InStock



Category PCB Header Brand HARWIN Condition New

Specifications

Country of Origin	United Kingdom
Voltage	120V
Brand	HARWIN
Orientation	Straight
Current	3A
Model	M80-8820342
Mount Type	Through Hole
Housing Material	Polyphenylene Sulphide
Contact Material	Phosphor Bronze
Series	Datamate L-Tek
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2mm
Contact Plating	Gold
Number of Contacts	3
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board, Wire-to-Board
Tail Pin Length	3mm

Key Features

Includes 3 gold-plated phosphor bronze contacts for reliable connections.
Offers a compact 2 mm pitch for space-saving PCB design.
Shrouded single-row design offers enhanced protection and polarisation.
Rated for 120V operation and 3A current per contact for versatile power management.
Robust construction with polyphenylene sulphide housing ensures durability in harsh conditions.
Supports a wide operating temperature range from -55°C to 125°C.
Board-to-board and wire-to-board capability for flexible applications.
Through hole, solder termination for secure PCB mounting.

Product Description

The HARWIN M80-8820342 is a Datamate L-Tek Series straight, through hole, shrouded PCB header engineered for demanding electronic interconnect applications. Featuring a 2 mm pitch and 3 phosphor bronze, gold-plated male contacts arranged in a single row, this connector offers both compactness and reliability, making it ideal for use where high density and robust mating performance are required.

This header is designed with a shrouded housing constructed from polyphenylene sulphide, providing mechanical protection against accidental contact, enhanced guidance, and polarisation during mating. A secure solder termination method ensures reliable and durable mounting to the PCB, while the straight orientation makes it suitable for vertical board stacking and modular assembly.

Built to withstand harsh operating environments, the M80-8820342 is rated for a wide temperature range from -55°C to 125°C. It supports current up to 3A per contact at 120V, making it suitable for both signal and low-power applications where reliability is essential. Gold plating on the contacts provides excellent conductivity and low contact resistance over high mating cycles.

This PCB header is part of the Datamate L-Tek series, recognized for its performance under vibration, shock, and mechanical acceleration. Use cases span industrial automation, instrumentation, military/aerospace, and demanding commercial electronics where robust interconnection is crucial.

Its through hole, wire-to-board and board-to-board compatibility, and tail pin length of 3 mm further enhance engineering flexibility for integration into custom circuits and assemblies.

The HARWIN M80-8820342 stands out due to its high reliability four-finger Beryllium Copper contact design in the Datamate family, polarised mouldings, COTS suitability, and compliance with pertinent international connector standards, making it a dependable choice for mission-critical electronic designs.
