SMC Pneumatic Guided Cylinder 32mm Bore CQM Series 15 mm Stroke Double Acting Aluminium Alloy Body CDQMB32-15

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Guided Cylinder 32mm Bore CQM Series 15 mm Stroke Double Acting Aluminium Alloy Body CDQMB32-15



Category Pneumatic Guided Cylinder Brand SMC Condition New

Specifications

Country of Origin	China
Brand	SMC
Body Material	Aluminium Alloy
Maximum Operating Pressure	1 Mpa
Height	45mm
Length	65mm
Model	CDQMB32-15
Gross Weight	228g
Width	58.5mm
Mount Type	Through Hole
Series	CQM
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-10°C
Stroke Length	15mm
Bore Diameter	32mm
Rod Type	Single
Action Type	Double Acting
Cushioning Type	Rubber
Guide Type	Slide Bearing
Maximum Piston Speed	500 mm/s

Key Features

Compact design with aluminium alloy body ensures durability and lightweight.
Double acting slide bearing guide provides smooth and precise piston movement.
Through hole mount type allows versatile installation in industrial applications.
Rubber cushioning type reduces impact noise and prolongs cylinder life.
Operates reliably between temperature range of -10°C to 70°C.
Capable of handling a maximum operating pressure of 1 Mpa.
Maximum piston speed is 500mm/s, suitable for fast actuation.
Suitable for automation in manufacturing, laboratory, and pneumatic fluid power systems.

Product Description

SMC CDQMB32-15 pneumatic guided cylinder is a compact and robust solution designed for precise linear actuation in demanding industrial environments. Featuring a 32mm bore diameter and 15 mm stroke length, this cylinder is constructed of hard anodized aluminium alloy that provides excellent strength while keeping the weight low at 228 grams. Its double acting action type and slide bearing guide design ensure reliable performance and accurate control in automation processes.

The cylinder is equipped with rubber cushioning to minimize impact and vibration, extending the service life of the device. Its through hole mount type facilitates straightforward integration into different pneumatic systems and machinery setups. The cylinder can operate safely within the temperature range of -10°C to 70°C and withstands a maximum operating pressure of 1 Mpa with piston speeds up to 500mm/s. These specifications make it ideal for use in factory automation, fluid power systems, material handling, and laboratory instrumentation.

The guided cylinder offers enhanced lateral load resistance, being two to four times higher than comparable series, allowing it to accommodate direct side loads without compromising performance. The magnetic piston feature available in this series enables position sensing compatibility for advanced control applications. Manufactured with high-quality aluminium alloy and designed for precision, the SMC CDQMB32-15 supports reliable operation with efficient footprint.

Compact aluminium alloy body for strength and lightness. Double acting guided cylinder with slide bearing for precision. Through hole mounting design for flexible installation. Rubber cushioning reduces noise and mechanical wear.

Temperature range suitable for diverse industrial environments. Maximum operating pressure of 1 Mpa for robust actuation. Maximum piston speed of 500mm/s for fast operations. Enhanced lateral load resistance for direct load handling.

This pneumatic guided cylinder is widely applicable in industrial, manufacturing, laboratory, and automation settings requiring high accuracy and durability. Available as part of the CQM series, it complements other SMC pneumatic products and accessories, providing seamless compatibility for integrated pneumatic systems. Explore more Pneumatic Guided Cylinders and actuators for precise control at EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The bore diameter of this model is 32mm.

It can withstand a maximum operating pressure of 1 Mpa.

The stroke length is 15mm.

The maximum piston speed is 500mm/s.

It operates reliably within a temperature range of -10°C to 70°C.

This model features a through hole mount type for versatile installation.

It uses rubber cushioning to reduce impact noise and prolong cylinder life.

The body is made of aluminium alloy, which ensures durability while keeping it lightweight.

The gross weight of this unit is 228 grams.

It features a double acting action type for effective operation.

This model is suitable for factory automation, fluid power systems, material handling, and laboratory instrumentation.

It offers enhanced lateral load resistance, being two to four times higher than comparable series, allowing it to accommodate direct side loads without compromising performance.
