SMC Pneumatic Guided Cylinder 20mm Bore, CQM Series, Double Acting, 25mm Stroke CDQMB20-25

SMC CDQMB20-25 Pneumatic Guided Cylinder is a precision-engineered device from the CQM series offering a 20mm bore diameter and a 25mm stroke length. This double acting pneumatic cylinder is designed with an aluminum alloy body that provides excellent durability while maintaining a lightweight construction of approximately 152 grams. The unit incorporates a slide bearing guide type, enhancing lateral load resistance to accommodate direct and side loads effectively, with resistance two to four times higher than standard series CQ cylinders.

Its non-rotatable design, including a magnetic piston, optimizes position sensing and reliability in automation processes. The cylinder supports industrial pneumatic actuation with a maximum operating pressure of 1 Mpa and piston speed up to 500mm/s. Rubber cushioning improves mechanical shock absorption and noise reduction at the stroke ends, enhancing the cylinder's operational lifespan.

The through hole mount facilitates integration with SMC CQS and CQ2 series cylinders, making it suitable for complex fluid power and automation systems in manufacturing, assembly lines, industrial machinery, HVAC, and laboratory automation applications. Its operational temperature range from -10°C to 70°C ensures dependable performance under varied environmental conditions. The carefully engineered dimensions, 36mm width and height with a 67mm overall length, allow compact yet robust installation in tight spaces.

This pneumatic guided cylinder is ideal for tasks that require precise linear motion combined with lateral force resistance, commonly found in packaging, material handling, and industrial process control environments. The SMC brand ensures adherence to industrial standards and continuous innovation in pneumatic components.

Compact and durable aluminum alloy construction. Double acting cylinder operation with magnetic piston standard. Slide bearing guide providing enhanced lateral load resistance. Rubber cushioning to reduce noise and wear.

Through hole mount compatible with related SMC series cylinders. Operating pressure support up to 1 Mpa. Wide operating temperature range from -10°C to 70°C. Lightweight design at 152 grams enables easy handling. Applications include manufacturing, automation, and fluid power systems.

Explore the full range of Pneumatic Guided Cylinders and SMC pneumatic components to optimize your fluid power applications with EnvMart’s trusted industrial catalog.
