SMC Pneumatic Guided Cylinder 50mm Bore, CQM Series, 35 mm Stroke, Double Acting, Aluminium Alloy Body CDQMB50-35

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Guided Cylinder 50mm Bore, CQM Series, 35 mm Stroke, Double Acting, Aluminium Alloy Body CDQMB50-35



Category Pneumatic Guided Cylinder Brand SMC Condition New

Specifications

Country of Origin	India
Brand	SMC
Body Material	Aluminium Alloy
Maximum Operating Pressure	1 Mpa
Height	64mm
Length	95.5mm
Model	CDQMB50-35
Gross Weight	701g
Width	80mm
Mount Type	Through Hole
Series	CQM
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-10°C
Stroke Length	35mm
Bore Diameter	50mm
Rod Type	Single
Action Type	Double Acting
Cushioning Type	Rubber
Guide Type	Slide Bearing

Key Features

Equipped with a durable aluminium alloy body for enhanced strength and lightweight.
Double acting cylinder with a 35 mm stroke length for precise pneumatic actuation.
Utilizes a single rod type with slide bearing guide for smooth operation and stability.
Rubber cushioning provides reliable impact absorption during operation.
Designed for operating pressures up to 1 Mpa ensuring robust performance.
Operating temperature range from -10°C to 70°C suitable for various industrial environments.
Maximum piston speed of 500 mm/s allowing efficient cycle times.
Non-rotatable design with hard anodized aluminium finish for corrosion resistance.

Product Description

SMC CDQMB50-35 Pneumatic Guided Cylinder features a 50mm bore and 35 mm stroke length, designed for high-precision pneumatic control in industrial applications. This double acting cylinder incorporates a robust aluminium alloy body with hard anodized surface treatment providing enhanced durability and corrosion resistance.

Its guided slide bearing system ensures smooth and stable motion, accommodating direct loads with lateral load resistance two to four times greater than standard CQ series. The cylinder has a single rod type and rubber cushioning to absorb impact forces efficiently during operation, enhancing service life and reliability.

Operating pressures up to 1 Mpa and a maximum piston speed of 500 mm/s allow for versatile use in demanding industrial, manufacturing, automation, and HVAC pneumatic systems. The compact dimensions (64 mm height, 80 mm width, and 95.5 mm length) allow integration in space-constrained assemblies while maintaining performance integrity.

The temperature operating range from -10°C to 70°C enables application flexibility in diverse environments. This model is ideal for automation tasks requiring guided pneumatic cylinders with precision and load handling capabilities.

Durable aluminium alloy body enhances strength and reduces weight. Double acting operation with 35 mm stroke for controlled pneumatic movement. Slide bearing guide type offers superior lateral load resistance and smooth sliding action.

Rubber cushioning reduces impact, increasing cylinder longevity. Suitable for pressures up to 1 Mpa in industrial pneumatic systems. Wide operating temperature range from -10°C to 70°C for flexible deployment. Compact and non-rotatable design ensures easy mounting through hole type.

This SMC guided pneumatic cylinder suits applications in mechanical automation, industrial manufacturing, HVAC controls, packaging machinery, and fluid power systems. It supports efficient pneumatic actuation where precision and durability are critical. Browse more pneumatic components and cylinders in EnvMart to complete your system setup.
