Jaeger Circular Connector, 8 Contacts, Panel Mount, Female, Standard Size, IP50/IP54, MIL-DTL-5015, Silver 5366 080 06

Free Delivery in India | Lowest Global Shipping Charges

Jaeger Circular Connector, 8 Contacts, Panel Mount, Female, Standard Size, IP50/IP54, MIL-DTL-5015, Silver 5366 080 06

Name: Jaeger Circular Connector, 8 Contacts, Panel Mount, Female, Standard Size, IP50/IP54, MIL-DTL-5015, Silver 5366 080 06
Brand: Jaeger
SKU: 145229
Price: 30.58 USD
Availability: InStock



Category Circular Connector Brand Jaeger Condition New

Specifications

Country of Origin	France
Brand	Jaeger
Orientation	Straight
IP Rating	IP50, IP54
Mount Type	Panel Mount
Termination Type	Solder
Maximum Operating Temperature	100°C
Minimum Operating Temperature	-50°C
Standards/Approvals	MIL-DTL-5015
Contact Plating	Silver
Number of Contacts	8
Contact Gender	Female
Shell Size	2
Connector Size	Standard

Key Features

The connector features a standard size shell with MIL-DTL-5015 compliance.
It has a straight orientation and solder termination type for secure contact.
Rated for operating temperatures from -50°C to 100°C.
It provides IP50 and IP54 ingress protection ratings for dust and water resistance.
Silver plating on contacts ensures reliable conductivity and corrosion resistance.
The product is manufactured in France ensuring quality and durability.
Compatible with Jaeger standard chassis plugs and sockets, supporting rapid series cable plugs.
Ideal for industrial applications requiring rugged and reliable circular connectors.

Product Description

Jaeger 5366 080 06 is a high-quality industrial circular connector designed for panel mount applications. Featuring 8 female contacts, this standard size connector is engineered to meet MIL-DTL-5015 standards, ensuring robust performance in demanding environments.

The connector supports a straight orientation and uses solder termination for secure and reliable electrical connections. It is rated for operating temperatures ranging from -50°C to 100°C, enabling use in extreme temperature conditions often found in industrial, manufacturing, and electronic systems.

Ingress protection ratings of IP50 and IP54 provide effective sealing against dust ingress and water spray, enhancing durability for harsh industrial settings. The silver-plated contacts deliver excellent electrical conductivity and resistance to corrosion, ensuring longevity of the connection.

Manufactured in France, this connector is part of the Jaeger standard and rapid range, offering compatibility with related chassis plugs and sockets. It is ideally suited for use in industries such as industrial automation, machinery assembly, HVAC control systems, and other commercial electronic applications where reliability and environmental protection are critical.

The connector has 8 contacts configured for female contact gender. Standard size shell (size 2) for consistent mounting and interface. Panel mount type facilitating easy integration into control panels or equipment housings.

Compliant with MIL-DTL-5015 standards ensuring high mechanical and electrical performance. Silver contact plating for enhanced conductivity and corrosion protection. Rated operating temperature range of -50°C to 100°C suits a wide variety of environments.

Ingress protection ratings IP50 and IP54 provide durability against dust and water. Termination by solder of the contacts guarantees stable electrical connections. Explore the full range of industrial Circular Connectors by Jaeger at EnvMart for reliable solutions in electronic component connectivity.
