C & K IP40 Black Tactile Switch Top 2.5 mm SPST 50mA 16 V dc Surface PTS810 SJG 250 SMTR LFS

Free Delivery in India | Lowest Global Shipping Charges

C & K IP40 Black Tactile Switch Top 2.5 mm SPST 50mA 16 V dc Surface PTS810 SJG 250 SMTR LFS

Name: C & K IP40 Black Tactile Switch Top 2.5 mm SPST 50mA 16 V dc Surface PTS810 SJG 250 SMTR LFS
Brand: C & K
SKU: 144895
Price: 0.62 USD
Availability: InStock



Category Tactile Switch Brand C & K Condition New

Specifications

Country of Origin	China
Brand	C & K
Height	2.5mm
Length	4.2mm
Model	PTS810 SJG 250 SMTR LFS
IP Rating	IP40
Width	3.2mm
Mount Type	Surface
Series	PTS810
Maximum Operating Temperature	85°C
Contact Configuration	SPST
Minimum Operating Temperature	-40°C
Terminal type	J Bend
Standards/Approvals	RoHS
Switch Operation	Momentary
Actuator Colour	Black
Actuator Length	2.5mm
Contact DC Voltage	16V dc
Actuator Style	Top
Switch Contact Current	50mA
Operating Force	4N
Mechanical Life	100000Operations

Key Features

This switch features a black top actuator with a 2.5 mm length.
It offers SPST (single pole single throw) contact configuration for momentary switch operation.
Designed with a J bend terminal type for surface mounting on PCBs.
The switch has an IP40 rating ensuring protection against solid objects larger than 1 mm.
Operating temperature ranges from -40°C to 85°C, suitable for harsh environments.
It supports a contact DC voltage of 16 V and a switch contact current of 50mA.
The actuation force required is 4N, delivering tactile feedback.
The switch provides a mechanical life of 100000 operations for reliability.

Product Description

C & K PTS810 SJG 250 SMTR LFS IP40 tactile switch top 2.5 mm is a compact microminiature surface mount switch designed for precision control applications. With a small footprint of 4.2 x 3.2 mm and a height of 2.5 mm, this switch is optimized for use where PCB space is limited.

The switch features a momentary operation with SPST-NO contact configuration and J bend terminal type for secure surface mounting. The actuator is a black top style with a length of 2.5 mm, providing tactile feedback with an operating force of 4N. It is rated to operate with a contact DC voltage of 16 V and switch contact current of 50mA.

Its IP40 rating offers protection from solid objects larger than 1 mm, suitable for indoor applications in environments requiring basic dust protection. The operating temperature range from -40°C to 85°C ensures performance in a variety of ambient conditions. The switch is RoHS compliant and designed for durability, with a mechanical life expectancy of 100000 operations.

This tactile switch series is widely used in industrial applications such as remote controls, control panels, keyless entry systems, and nomad devices where reliable momentary switching with tactile feedback is required.

This switch features a black top actuator with a 2.5 mm length. It offers SPST (single pole single throw) contact configuration for momentary switch operation. Designed with a J bend terminal type for surface mounting on PCBs.

The switch has an IP40 rating ensuring protection against solid objects larger than 1 mm. Operating temperature ranges from -40°C to 85°C, suitable for harsh environments. It supports a contact DC voltage of 16 V and a switch contact current of 50mA.

The actuation force required is 4N, delivering tactile feedback. The switch provides a mechanical life of 100000 operations for reliability. The compact design makes it ideal for remote controls, control panels, and keyless entry systems.
