C & K Rotary Coded DIP Switch Surface Mount Extended Actuator SDA08H1SBD
Specifications
| Country of Origin | India |
|---|---|
| Brand | C & K |
| Model | SDA08H1SBD |
| Mount Type | Surface Mount |
| Actuator Type | Extended |
| Switch Contact Rating | 100 mA @ 5 V dc / 25 mA @ 24 V dc |
| Electrical Life | 1000 cycles minimum |
Key Features
- Designed for telecom, computers, test equipment, security, and instrumentation use.
- SPST switch type with surface mount terminals for efficient PCB integration.
- Extended actuator provides easy mechanical operation and device accessibility.
- Electrical life of minimum 1000 cycles ensures durability in demanding environments.
- Part of C & K SDA Series featuring low-profile design with precision engineering.
Product Description
C & K SDA08H1SBD Rotary Coded DIP Switch Surface Mount with Extended Actuator is a precision-engineered component used in electronics and industrial systems. It belongs to the renowned C & K SDA series, known for its low-profile design that optimizes space on printed circuit boards.
This switch type is a single pole single throw (SPST) device, featuring surface mount terminals that facilitate robust and efficient soldering on modern PCB assemblies. The extended actuator enhances manual operation, providing accessibility and ease of use in various application settings.
Its switch contact rating supports 100 mA at 5 V dc and 25 mA at 24 V dc, allowing it to function reliably across low current and voltage control circuits. With a minimum electrical life of 1000 cycles, this switch is engineered for solid endurance in telecom equipment, computing hardware, test instruments, security systems, and instrumentation projects.
Applications span industrial automation, communication devices, laboratory instrumentation, and electronic manufacturing, making it ideal for multiple commercial and industrial sectors where reliable switching is critical.
Designed for telecom, computers, test equipment, security, and instrumentation use. SPST switch type with surface mount terminals for efficient PCB integration. Extended actuator provides easy mechanical operation and device accessibility.
Rated for switch contact current: 100 mA at 5 V dc or 25 mA at 24 V dc for versatile compatibility. Electrical life of minimum 1000 cycles ensures durability in demanding environments. Part of C & K SDA Series featuring low-profile design with precision engineering.
Explore more components in the Rotary Coded DIP Switch category at EnvMart for your industrial electronics needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is a single pole single throw (SPST) switch, designed for efficient operation in various applications.
The electrical life of the SDA08H1SBD is a minimum of 1000 cycles, ensuring longevity in demanding environments.
It is rated for a switch contact current of 100 mA at 5 V dc and 25 mA at 24 V dc, allowing for versatile compatibility in low current and voltage control circuits.
This model features a surface mount design, which facilitates robust and efficient soldering on printed circuit boards.
It is suitable for use in telecom equipment, computers, test equipment, security systems, and instrumentation projects.
The SDA08H1SBD is equipped with an extended actuator, which enhances manual operation and accessibility.
This model is manufactured in India, contributing to its global availability.
It is part of the C & K SDA series, known for its low-profile design and precision engineering.
The extended actuator provides easy mechanical operation, enhancing device accessibility in various application settings.
Key features include surface mount terminals, an extended actuator, and a minimum electrical life of 1000 cycles.
Yes, this switch is ideal for industrial automation, communication devices, laboratory instrumentation, and electronic manufacturing.
The design focuses on optimizing space on printed circuit boards while ensuring robust performance in various electronic applications.
