Eaton ZB Series Overload Relay 1 NO/1 NC, 12-16A F.L.C, 16A Contact Rating, 6W Power, 500V AC Control Voltage 290168 ZB12-16

Eaton 290168 ZB12-16 Overload Relay is part of the ZB series designed to safeguard motors in automation, electronics, electrical, and mechanical industries. It provides reliable overload protection with a motor full load current (F.L.C) rating adjustable from 12 to 16 amperes and supports relay contact currents of up to 16 amperes.

With 1 normally open (NO) and 1 normally closed (NC) contact, this device can efficiently manage load circuits while maintaining safe operational conditions. Its 500V AC control voltage and 690V AC contact voltage rating make it suitable for high-voltage industrial environments requiring robust relay performance.

The overload relay mounts directly onto contactors, ensuring compact, space-saving installations. Its screw terminal design facilitates stable, secure connections, while automatic and manual reset options offer flexible operational control to suit application needs.

Measuring 88mm in length and depth, with a 45mm width, and rated IP20, this relay withstands indoor industrial conditions. It operates reliably within a temperature range of -5°C to 55°C, ensuring industrial suitability across varying ambient conditions.

Certified to international standards such as CE, UL (including UL Category Control No.: NKCR), VDE 0660, IEC/EN 60947-4-1, and CSA certifications, this Eaton overload relay meets stringent quality and safety requirements.

This model incorporates two auxiliary contacts enhancing control capabilities and integrates seamlessly within automation systems for reliable motor protection.

Typical industrial applications include use in automation systems for current regulation, electronic control circuits requiring high contact ratings, electrical panels ensuring operational safety, and mechanical systems needing dependable overload protection.

Features 1 normally open and 1 normally closed contacts for versatile control. Adjustable current range from 12 to 16 amperes for flexible motor protection. Automatic and manual reset methods enhance operational convenience.

Screw type terminals provide secure and stable electrical connections. Suitable for control voltages up to 500V AC and contact voltage rated at 690V AC. Compact dimensions measuring 88mm length, 88mm depth, and 45mm width.

IP20 protection ensures reliable performance in controlled environments. Complies with international standards including CE, UL, VDE, IEC, and CSA approvals. Operating temperature range from -5°C to 55°C for diverse industrial conditions.

Includes two auxiliary contacts for enhanced circuit control. Explore the wide range of Eaton industrial automation products and Overload Relays available at EnvMart for your application needs.
