C & K IP40 Blue Tactile Switch Button SPST 50mA 250V AC 12V DC Through Hole PTS645SM952 LFS
Specifications
| Country of Origin | China |
|---|---|
| Brand | C & K |
| Height | 2mm |
| Length | 6mm |
| Model | PTS645SM952 LFS |
| IP Rating | IP40 |
| Width | 6mm |
| Mount Type | Through Hole |
| Series | PTS |
| Maximum Operating Temperature | 60°C |
| Contact Configuration | SPST |
| Switch Configuration | (On)-Off |
| Minimum Operating Temperature | -20°C |
| Terminal type | Terminal |
| Standards/Approvals | RoHS |
| Switch Operation | Momentary |
| Actuator Colour | Blue |
| Contact DC Voltage | 12V dc |
| Actuator Style | Button |
| Actuator Orientation | Vertical |
| Switch Contact Current | 50mA |
| Operating Force | 1.6N |
| Mechanical Life | 100000Operations |
| Contact AC Voltage | 250V ac |
Key Features
- Compact 6mm x 6mm footprint and 2mm height for space-constrained applications.
- Blue actuator button with vertical orientation and through-hole mount style.
- Operates at an actuation force of 1.6N with a mechanical life of 100,000 operations.
- Designed for contact ratings of 50mA at 250V AC and 12V DC.
- Operates within temperature range from -20°C to 60°C ensuring versatility.
- RoHS compliant and manufactured in China for quality assurance.
- Suitable for industrial, consumer electronics, instrumentation, and computer applications.
Product Description
C & K PTS645SM952 LFS tactile switch is a high-quality momentary push-button switch with a single-pole single-throw (SPST) contact configuration. It features a compact 6mm by 6mm footprint and a low profile height of 2mm, optimized for use in densely packed electronic assemblies.
The switch actuator is blue in color, styled as a button, and oriented vertically. It utilizes through-hole terminal mounting ensuring robust physical and electrical connection in printed circuit boards.
Designed for reliable operation under a contact current rating of 50mA at 250 volts alternating current and 12 volts direct current, this switch adapts well to control and signal circuits. The operating force of 1.6 Newtons and a mechanical endurance rated at 100,000 cycles assures long service life under repeated usage.
Operating temperature range from -20 degrees Celsius to 60 degrees Celsius enables deployment in varied ambient conditions. The product complies with RoHS environmental standards, underscoring its green manufacturing credentials.
This tactile switch is part of the PTS645 series by C & K, known for colored coded actuators facilitating easy force identification and multiple actuator lengths for application flexibility. The IP40 ingress protection rating makes it suitable for indoor equipment with limited exposure to particles.
Typical applications include industrial control panels, consumer electronic devices, instrumentation, and computer input peripherals where precision tactile feedback and durability are required.
Compact size for space-limited installations. Color-coded actuator enhances operational clarity. Sturdy through-hole mount for secure PCB attachment. Meets RoHS compliance for hazardous substance reduction. Ideal for a broad range of electronic and industrial uses.
Explore the full range of Tactile Switches available in the Electronics & Electricals category at EnvMart for comprehensive solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The switch features a single-pole single-throw (SPST) contact configuration, allowing for a simple on-off operation.
This model has a compact footprint of 6mm x 6mm and a height of 2mm, making it suitable for space-constrained applications.
It operates within a temperature range of -20°C to 60°C, allowing for versatility in various ambient conditions.
The tactile switch requires an actuation force of 1.6 Newtons for operation.
It has a mechanical life rated at 100,000 operations, ensuring longevity under repeated use.
The switch is rated for a contact current of 50mA at 250V AC and 12V DC, making it suitable for various control and signal circuits.
It utilizes a through-hole mounting style, ensuring a robust physical and electrical connection in printed circuit boards.
Yes, it complies with RoHS standards, which ensures the reduction of hazardous substances in its manufacturing.
The actuator is blue in color and is styled as a button with vertical orientation.
This tactile switch is suitable for applications in industrial control panels, consumer electronics, instrumentation, and computer input peripherals.
It has an IP40 ingress protection rating, making it suitable for indoor equipment with limited exposure to particles.
The tactile switch is manufactured in China, ensuring quality assurance during production.
