SMC Pneumatic Guided Cylinder 8mm Bore Double Acting 20mm Stroke MXQ8A-20Z

SMC MXQ8A-20Z pneumatic guided cylinder is a high-quality component part of the MXQA series, offering an 8mm bore diameter and 20mm stroke tailored for precision pneumatic actuation. This double acting cylinder provides reliable force and positioning with a maximum operating pressure of 0.7 Mpa.

Manufactured with special stainless steel, the cylinder body ensures enhanced durability and corrosion resistance, making it suitable for industrial, manufacturing, laboratory, and fluid power applications. Rubber cushioning reduces noise and mechanical shock, improving operational life and user comfort.

The compact form factor includes dimensions of 78.5mm length, 41mm width, and 23mm height while maintaining a lightweight construction at 160 grams. The cylinder is designed to operate in a temperature range of -10°C to 60°C, allowing reliable functionality in various environmental and industrial settings.

Additional design features include a hole lateral mount with through hole capabilities, supporting flexible installation. The rod is single type, optimized for guided precision movements with a maximum piston speed of 500 mm/s to improve cycle times.

This product complies with RoHS standards, reflecting environmentally responsible manufacturing. Originating from France, the SMC MXQ8A-20Z is engineered for applications such as pick and place, precision placement of workpieces, low friction transport, pallet and conveyor positioning, vertical handling, and Z-axis actuation.

Constructed from special stainless steel for superior corrosion resistance. Double acting action type for efficient pneumatic control. Maximum operating pressure of 0.7 Mpa suitable for various industrial applications. Equipped with rubber cushioning to reduce noise and impact.

Compact design with dimensions 78.5mm length, 41mm width, and 23mm height. Operating temperature range from -10°C to 60°C ensures performance in varied environments. Lightweight at 160 grams for ease of installation. Complies with RoHS standards for environmental safety.

This pneumatic guided cylinder is ideal for industrial pneumatic systems requiring precise, repeatable linear motion including manufacturing automation, material handling, and assembly operations. Browse our comprehensive Pneumatic Guided Cylinder category for additional options and configurations from trusted brands like SMC on EnvMart.
