Amphenol Industrial SURLOK PLUS RADSOK EV Connector Female 35mm² Wire, Panel Mount, 150A SLPIRB35CPSB0 / C10-731950-130
Specifications
| Country of Origin | China |
|---|---|
| Brand | Amphenol Industrial |
| Colour | Black |
| Orientation | Straight |
| Current | 150A |
| Height | 30mm |
| Model | SLPIRB35CPSB0 / C10-731950-130 |
| Depth | 53.7mm |
| IP Rating | IP67 |
| Connector Type | RADSOK |
| Width | 30mm |
| Mount Type | Panel Mount |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | SURLOK PLUS |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Pin Diameter | 8mm |
| Number of Rows | 1 |
| Wire size | 35mm² |
| Operating Voltage | 1000V |
| For Use With | SurLok 1-Position Plug |
| Standards/Approvals | UL 94-V0 |
| Number of Contacts | 1 |
| Contact Gender | Male |
| Connector Gender | Female |
| Better World Claim | Renewable Energy Solution |
Key Features
- Compact and quick mating compression lug with high tensile connection strength.
- Features a keyed 8mm pin diameter to prevent mismating and ensure secure connections.
- Rated for operating voltages up to 1000V and a temperature range from -40°C to 125°C.
- Environmental sealing with IP67 rating and UL 94-V0 rated thermoplastic housing for durability and safety.
- Suitable for electric vehicle, rail mass transit, medical, process control, and battery management applications.
- Spring locking mechanism for secure and touch-proof connection.
- Panel mount flange design enabling versatile installation.
- Copper alloy contacts for optimal conductivity and corrosion resistance.
Product Description
Amphenol Industrial SLPIRB35CPSB0 / C10-731950-130 SURLOK PLUS RADSOK EV Connector Female is engineered to provide reliable, field-installable electrical connections with high conductivity and durability. This connector utilizes R4 RADSOK technology that assures a robust and highly conductive contact interface designed for 35mm² wire termination.
The connector includes a panel mount flange and a spring locking mechanism, enabling a touch-proof, quick mating operation. Its keyed design with a 90-degree key prevents mismating, enhancing connection reliability in demanding industrial environments.
Designed to operate safely at voltages of up to 1000V and currents up to 150A, this connector withstands environmental challenges with an IP67 ingress protection rating protecting against dust and water ingress. The housing is made of durable thermoplastic material with UL 94-V0 flammability rating, while contacts are fabricated from copper alloy, optimizing electrical performance and corrosion resistance.
This connector's temperature tolerance ranges from -40°C to 125°C, making it suitable for a broad range of industrial and commercial applications including electric and hybrid vehicles, rail mass transit systems, medical equipment, battery management systems, and process control installations. Its straight orientation and panel mount installation facilitate versatile usage scenarios.
Compact, environmentally sealed, and robust design with RADSOK technology. Keyed to avoid mismating and ensure secure electrical contacts. High current carrying capacity up to 150 Amperes at 1000 Volts. Thermoplastic housing with UL 94-V0 rating and copper alloy contacts.
IP67 rated for harsh industrial environments. Suitable for electric vehicles, rail, medical, and energy storage systems.
Overall, this connector is an essential component for high-performance, durable EV and industrial power connections. Explore more options and compatibility in the Amphenol SURLOK PLUS EV Connector range on EnvMart for professional-grade electrical solutions.
